DWC-P336WMW
Wall mount bracket for white IP PTZ cameras
Quick Start Guide
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
NOTE: Download all your support materials and tools in one place
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the search bar. Results ‘Search by Product’
for applicable part numbers will populate automatically based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
WHAT’S IN THE BOX
4x plastic anchors (8pi) 4x nuts (M8)
4x hex tapping screws (8x50) 4x spring washers (M8)
1x hex Allen wrench (2.5) 1x quick setup guide
1x PT plug tool
INSTALLING THE MOUNTING ACCESSORY
Quick Start Guide
Set screw (1x)
Safety wire
Plastic anchor (4x)
Tapping screw 8x35 (4x)
Mounting bracket (1x)
Access plate
Machine screw 3x5 (2x)
Adapter (Optional)
PT 1.25 inch (1x)
Set screw (1x)
PF 1.25 inch
Start point Set point
Twist
(Long indicator) (Short indicator)
Rev Date: 01/20
Copyright © Digital Watchdog. All rights reserved.
SpeciïŹcations and pricing are subject to change without notice.
3.77” (96mm)
4.7” (120mm)
4.5” (116mm)
5.5” (140mm)
4x 0.35” (9mm)
1.06”
(27mm)
11.33” (288mm)
PF 1-1/2"
1. Using the wall mount, mark and drill the mounting holes on the surface using the wall mount ïŹ‚ange.
2. Pull wires through to connect to the PTZ camera from the ceiling.
3. Using the plastic anchors and screws*, mount and secure the wall mount bracket to the mounting surface.
4. Open the access plate and pull out
cables through the rectangular
access hole.
5. Attach the 1.5 -inch adapter to the
ceiling mount bracket and ïŹx it
using the set screw.
6. Attach the camera’s safety wire
to the ceiling mount bracket and
organize cables.
7. Close the access plate of the
mounting bracket.
8. Push in and turn the camera
clockwise into the adapter. Fix it
using the set screw of the adapter.
