Seite 1/16
1
Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343
Instruction Manual
Extending 4K & 1080p HDMI
using single Cat5e/6
eX-35-4K
WyreStorm Low Prole 4K HDBaseT Extender
Set with 2-Way IR, RS232 and POH
(4K: 35m/115ft - 1080p: 70m/230ft)
Thank you for choosing this WyreStorm product.
Please read these instructions carefully before installing to avoid complications later.
2Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343
Contents
1. Introduction
CONTENTS, INTRODUCTION AND FEATURES
2. Features
Get Real. Think Thin.
Pushing technology and design to the limit, the EX-35-
4K extender set oers long distance HDMI 4K and HD
distribution and control over UTP within an incredibly low
prole chassis of just 15mm for a greatly reduced form
factor behind even the slimmest display wall plate to
make installation a dream.
Featuring streamlined Class B HDBaseT technology
for projects that demand the benets of HDBaseT
transmission, but perhaps do not require full Class
A specication, the EX-35-4K supports 70m/230ft
transmissions of 1080p@60Hz and 36bit Deep Color HD
Introduction
Features
Safety Precautions
Package Contents
Connection & Operation
i. Typical Application
ii. RJ45 Termination & Distance
iii. Initial Connection
iv. IR/RS232 Control Connection
v. Updating RS232 Settings
Maintenance
Product Service
Panel Descriptions
1
2
3
4
5
6
7
8
9
10
12
13
Mail In Service
Warranty
i. Warranty Limits and Exclusions
Installation Notes
Specication
Troubleshooting
General FAQ
14
11
audio, 100W power, discrete bidirectional control via IR
and RS232 all along a single Cat5e/6 cable to display
zones.
UltraHD 4K transmissions are supported up to 35m/115ft
over Cat6 at 30fps with chroma sub-sampling color
palette of 4:2:2 and automatic internal handling of EDID
and HDCP 2.2 between connected source/display
devices.
Including serial control support with compatibility with
leading control systems and switchable RS232 selection
for rmware updates, improved 18v power connectivity is
also oered via threaded DC power port for standard and
locking DC power plugs on both transmitter and receiver,
should it be required.
Operation status is illustrated by panel LED indicators for
power supply, signal status for display connection, HDCP
2.2 in signal, and a HDBaseT link indicator to assess
the presence of transmissions and help identify potential
issues.
WyreStorm 4K HDBaseT solutions oer the features,
exibility and compatibility demanded by modern
integrations while future-proong for tomorrow, combined
with an ease of use and cost-eciency for reliable
distribution and control of digital content over distance
whether in a residential or commercial setting.
For further information on this product and other
WyreStorm ranges, visit our website or download our
latest product guide. wyrestorm.com
• Low prole chassis of 15mm / 0.6” for easier, more
convenient installations behind screens at display
zones.
• Extender set capable of HDMI transmissions using
single cable Cat5e/6 cable under recommended
conditions*:
- 35m/115ft: 3840 (UHD) 4096 (DCI) 2160 4K
video/24bit True Color @30Hz with 4K Chroma
subsampling color palette 4:2:2
- 70m/230ft: 1920x1080p HD video/36bit Deep
Color@60Hz
• Transmits discrete wide-band two-way IR control
signal / serial commands together within the HDMI
signal over a single Cat5e/6
• One-way PoH (Power over HDBaseT) 18v DC locally
powered Transmitter passes power along the Cat5e/6
to remotely power the Receiver - no mains power
required at display zones
3
Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343
SAFETY PRECAUTIONS AND PACKAGE CONTENTS
3. Safety Precautions
WARNING
To reduce the risk of re, electric shock
or product damage:
• Cable termination follows IEEE-568B standards
• Multichannel audio supports 7.1 DTS Master HD and
Dolby True HD
• Robust Class B HDBaseT transmission technology
for stable 4K/HD distribution and control resistant
to electrostatic and environmental interference
compared to conventional UTP transmission
• Supports all high denition resolutions: 4K UHD &
DCI), 1080p, 1080i, 720p with screen refresh rates
support of 24Hz, 30Hz (4K) 50Hz and 60Hz (1080p)
• HDMI v1.4 with full 3D compatibility up to 1080p -
frame packing/sequential (Blu-Ray) and interlaced
stereoscopic (satellite/ cable broadcasts)
• Switchable RS232 fucntion mode on Transmitter and
Receiver for rmware update
Note: Serial control via RS232 only supported when
connected to a compatible HDBaseT transmission
device. Check website or contact WyreStorm
representative for compatibility
• Receivers cascadable up to 7 times within a single
output zone using another EX-35-4K Transmitter or
compatible HDBaseT transmission device
• Threaded bushings on allow use of both standard and
locking DC power plugs
• Visual LED indication for power supply to units, signal
status to show established display connection, HDCP
2.2 presence in signal and HDBaseT link
• HDCP 2.2 compliant
• Automatically adjusts feedback, equalization and
amplication of signal for easy installation
• Energy ecient universal power supplies included
• Mounting brackets and IR connections included
*Recommended transmission conditions - cable
run within specied distance range of product, no
electrical interference, the use of straight cable runs
with no bends or kinks and no patch panels or wall
outlets used. Please be advised that the presence
of any of these factors in your installation may
compromise bandwidth and signal strength.
1. Do not expose this apparatus to rain, moisture,
sprays, drips or splashes and ensure that no
objects containing liquids are placed on the
apparatus, including cups, glasses and vases.
2. Do not place this unit in a conned space such as
enclosed shelving, cabinets or bookshelves.
Ensure the unit is adequately ventilated.
3. To prevent the risk of electric shock or re hazard
due to overheating, do not cover the unit or
obstruct ventilation openings with material,
newspaper, cardboard or anything that may restrict
airow into the unit.
4. Do not install near external heat sources such as
radiators, heat registers, boilers or any device that
produces heat such as ampliers or computers and
do not place near sources of naked ame.
5. Unplug apparatus from power supply during
lightening storms or when unused for long periods
of time.
6. Protect the power cable from being walked on,
pinched or restricted in any way, especially at plug
connections.
7. Only use attachments/accessories specied by the
manufacturer.
8. Units contain non-servicable parts - Refer all
servicing to qualied service personnel.
4. Package Contents
WyreStorm EX-35-4K extender set comprising of:
1 x TX-35-4K Transmitter
1 x RX-35-4K Receiver
1 x 18V DC 1A universal power supply
2 x 3.5mm phoenix male connector (3 pin)
2 x Wide-band IR emitter
2 x Wide-band IR receiver (30-50KHz)
2 x Pairs of EX-35-4K mounting brackets
1 x Printed Quickstart guide*
*Quickstart and full manual downloadable from product
page at wyrestorm.com
