VSP-9970
Issue 5
1 947941
V-9970
SINGLE ZONE ONE-WAY
STATION LEVEL PAGE CONTROL
INTRODUCTION
The V- -9970 is a Single Zone One way Station Level
Page Control designed to provide ring trip and page
access circuitry for use on standard telephone lines
(PABX, Centrex or C. O. line connections). These
instructions contain the specifications and
information necessary to install, operate and maintain
the Single Zone One-way Station Level Page Control.
Regulatory Information
This equipment has been tested and found to comply
with the limits for a Class A digital device pursuant to
Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when this equipment is operated in a
commercial environment. This equipment generates,
uses and can radiate radio frequency energy and if
not installed and used in accordance with the
instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in
a residential area is likely to cause harmful
interference in which case the user will be required to
correct the interference at his/her own expense.
• FCC Registration #: BAFUSA- - -21973 PA N
• Ringer Equivalence #: AC 0.6B/DC 0.1B
This equipment is to be installed only in restricted
access areas (Such as dedicated equipment rooms or
equipment closets) in accordance with Articles
110- - -16, 110 17 and 110 18 of the National
Electrical Code, ANSI/NFPA 70.
SPECIFICATIONS
Features
• Automatic Gain Control
• Paging from standard phone lines
• Suppression of unwanted sounds (Pops and
tones)
• Page tone verification
• Page disconnect on tones or C.O. open loop
• Feedback reduction
• Power on LED
• Page in progress LED
• User contacts provided
• - -12VDC or 24VDC operation
• Background music input
• VOX silence disconnect, user selectable
• Absolute timeout, user selectable
• Connects to telephone line via standard RJ11C
jack
• CMOS DSP power efficient green technology
(Uses only 1 Watt average @ 12 Volts when
utilizing a VP-412A - 2 Watts during page)
• FCC Part 68 Compliant
• UL Listed
2
Nominal Specifications
Technical
DC Voltage Input: - -12VDC or 24VDC @ 165mA
Fusing: 1/2 Amp resettable polyswitch
Voice Paging
Ringing Detection: 38 - 130 Volts AC
Tip/Ring Input Level: - -20dBm 0dBm
S/N Ratio: 55dBm
Tip/Ring Tone Out: - -6dBm (1.09Vp p)
Noise Rejection: 1.5Vp-p common mode tip/ring
60Hz Rejection: 2.0Vp-p common mode tip/ring
Paging Voice Out: - -10dBm (0.693Vp p)
Voice Response: 150 - 5000Hz
Tip/Ring Impedance: 600 Ohms
with loop current 20 - 80mA
REN: 0.2A
Silence Timeout: Adjustable from 1 - 31 seconds
Absolute Timeout: Adjustable 4 - 124 seconds
Dial Tone Disconnect Frequencies: 350/440,
440/480, 440/620, 480/620, 525/660Hz
Background Music
Music Response: 20 - 20kHz
Music Input Level: - - - -23 0dBm (0.15 2.2Vp p)
S/N Ratio: 75dBm
PS Rejection: 52dBm
Music Out: - -17dBm (0.311Vp p) nominal
(User adjustable)
Music Adjustment: 0.1 - 1.1X
Environmental
Dimensions: 8.25" H x 4.50" W x 2.35" D
(20.96cm H x 11.43cm W x 5.97cm D)
Weight: 1.5 lbs. (.68 kg)
Operating Temperature: 0 to +50oC
Storage Temperature: -40 to +85oC
Cooling: Free Air Convection
Humidity: 10 - - 90% (Non condensing)
Shock: 10G
DESIGN
The Valcom V-9970 is designed to provide paging
access from a standard analog PABX station number,
a C. O. line or analog Centrex line. The Page Control
incorporates the latest technology Digital Signal
Processor (DSP) to recognize and transfer speech
only, thus eliminating unwanted noises such as pops
and tones. A discriminating Automatic Gain Control
(AGC) is provided to make quiet pages louder and
loud pages quieter.
The Single Zone One-way Station Level Page Control
provides a music input with volume control for
background music and an additional 1 Amp internal
relay output (This input closes during a page to
provide user page notification if desired).
INSTALLATION
The V-9970 Page Control must be powered by a Class
2 Listed, - -12VDC output transformer or by 24VDC
NEC Class 2 power source.
When using this equipment, basic safety precautions
should be followed to reduce the risk of fire, electric
shock and injury to persons:
1. Never install telephone wiring during a
lightning storm.
2. Never install telephone jacks in wet locations
unless the jack is specifically designed for
wet locations.
3. Never touch uninsulated telephone wires or
terminals unless the telephone line has been
disconnected at the network.
4. Use caution when installing or modifying
telephone lines.
Mounting/Connections
1. Remove the metal mounting plate from the
rear of the V-9970 enclosure. Using two #6
3/4" wood screws, mount the plate in a
vacant space on the backboard with the
telephone system common equipment. Both
mounting holes must be utilized to insure
secure mounting of the unit.
2. Open the V-9970 enclosure to allow access
to connections and option switches. Slide
the rear of the unit (Contains the board) onto
the mounting plate.
3. Using a 1/8" blade screwdriver, connect Tip
and Ring from the Valcom amplified speakers
to PAGE OUT on the V-9970 screw terminals.
4. Attach two wires from a music source output
to the terminal screws labeled SIG MUSIC
and COM IN. Volume is adjusted by rotating
R13 clockwise.
5. A 1 Amp internal relay input is supplied to
provide user page notification. Attach two
wires from the notification equipment to the
V-9970 if this feature is to be used.
6. Plug the RJ11C jack from a single line phone
to connector J2 on the V-9970.
7. Connect 12V power supply (VP-412A) to
connector J1 (If using the 24V option,
connect the power supply to the terminals
marked COM and 24V).
8. Set dip switches for desired options. (See
chart following for settings).
Note: Dip switches for user options should be set for
desired functions prior to replacing the enclosure
cover and plugging in the power supply.
9. Replace cover and plug in power supply.
OPERATION
3
To make a page from a remote location, dial the phone
number the page adapter is connected to and issue
page. The background music will fade and the page
will be heard through the amplified speakers. When
the page ends, the music will resume.
Note: For most efficient operation, use Valcom
VP- -412A, 120VAC plug in power supply.
TECHNICAL ASSISTANCE
When trouble is reported, verify the unit is properly
connected and there are no broken connections
leading to this unit.
Assistance in troubleshooting is available from the
factory. When calling, you should have a VOM and a
test set and be calling from the job site. Call (540)
563-2000 and ask for Technical Support or call (540)
767- -1555 for Valcom 24 hour Faxback System or visit
our website at http://www.valcom.com.
Valcom equipment is not field repairable and fuses are
not user replaceable. Valcom, Inc. maintains service
facilities in Roanoke, VA. Should repairs be
necessary, attach a tag to the unit clearly stating
company name, address, phone number, contact
person and the nature of the problem. Send the unit
to:
Repair and Return Dept.
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019-5056
VALCOM LIMITED WARRANTY
Valcom, Inc. warrants its products to be free from defects in materials and workmanship under conditions of normal use and service
for a period of one year from the date of shipment. The obligation under this warranty shall be limited to the replacement, repair or
refund of any such defective device within the warranty period, provided that:
1. inspection by Valcom, Inc. indicates the validity of the claim;
2. the defect is not the result of damage, misuse or negligence after the original shipment;
3. the product has not been altered in any way or repaired by others and that factory sealed units are unopened (A service
charge plus parts and labor will be applied to units defaced or physically damaged);
4. freight charges for the return of products to Valcom are prepaid;
5. all units ‘out of warranty’ are subject to a service charge. The service charge will cover minor repairs (Major repairs will be
subject to additional charges for parts and labor).
This warranty is in lieu of and excludes all other warranties, expressed or implied, and in no event shall Valcom, Inc. be liable
for any anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the
purchase, operation or use of the product.
This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the
carrier should be notified immediately. Claims for such damage should be filed with the carrier involved in accordance with the
F.O.B. point.
Headquarters: In Canada
Valcom, Inc. CMX Corporation
5614 Hollins Road 35 Van Kirk Drive #11 and 12
Roanoke, VA 24019-5056 Brampton, Ontario L7A 1A5
Phone: (540) 563-2000 Phone: (905) 456-1072
FAX: (540) 362-9800 FAX: (905) 456-2269
