LIGHT-DUTY ROTATING WALL
(7170-0595 CONFIGURATION)
MAX
3
SMALL KNUCKLE
(APPLY LOCTITE TO BOTH ENDS)
MAX
3
TALL STATIONARY WALL MOUNT
(7170-0596 CONFIGURATION)
MAX
3
THREAD
ADAPTER
(APPLY LOCKTITE
TO BOTH ENDS)
MAX
3
100mm
EXTENSION TUBE
This instruction sheet covers the installation of the Gamber-Johnson(7170-0595 & 7170-0596). This kit
is intended to mount a dock/cradle to a wall and not intended for use in a vehicle.
Figures below show the correct assembly procedure.
The installer is responsible for suppling hardware (type, size, quantity ) for the surface.
(example: Lag Screws, Machine Bolts, Concrete Anchors).
MAX
3
75mm ADAPTER PLATE
© Copyright 2017 Gamber-Johnson, LLC
7170-0595 & 7170-0596
LIGHT-DUTY ROTATING WALL MOUNT
TALL STATIONARY WALL MOUNT
PS-001
Printing Spec:
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
Form
Revision
Product
INSTALLATION INSTRUCTIONS
REV A
INST-796
Product Mounting Disclaimer
Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage
of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson
products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is
required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications
and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.
