Seite 1/3
Rev.D INST-715
required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications
Product Mounting Disclaimer
Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage
of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson
products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is
and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.
PS-004
7160-0821, 7160-0821-01
Form
INSTALLATION INSTRUCTIONS
Product Revision
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
Ford Utility Police Interceptor Close-To-Dash Mount
Printing Spec:
•You must read and follow all of these installation instructions. Failure to follow the installation
instructions may result in serious bodily injury or death
•DO NOT install or use this assembly in the area in which the airbag on the vehicle may be
deployed. The installer and user of this assembly are responsible for installing and using this
assembly outside the area in which an airbag may be deployed. (See Product Mounting
Disclaimer Below)
•If the installation of the equipment requires that the equipment (or any additional equipment
that is added to the installation) be placed in front of an airbag, the airbag should be
deactivated. In order to secure permission for deactivating the airbag you must contact the
National Highway Traffic Safety Administration at 1-800-424-9393 to gain permission to do so.
If you have any questions or need assistance, call Gamber-Johnson at 1-800-456-6868.
•High speed vehicle turns may cause parts fo the assembly to swivel, interfering with the driver
or other equipment.
•Keep these installation instructions with the product and readily available in the vehicle
for future reference of other users of the product.
•Additional copies of the installation instruction can be obtained from Gamber-Johnson.
If you need assistance or have any questions, go to www.gamberjohnson.com or
call Gamber-Johnson at 1-800-456-6868.
•DO NOT remove the warning label from the product under any circumstances.
1/3
© Copyright 2018 Gamber-Johnson, LLC
factory dash
cover panel
plastic clips
plastic clips
The Ford Utility Police Interceptor Close-To-Dash mount is designed
specifically to mount on a Gamber-Johnson vehicle specific console box
(7160-0412) and to attach to the dash of the Ford Utility.
metal dash
cover panel
2/3
Installing the mount:
Step 1. Remove the dash cover panel using an 8mm hex socket.
Step 2. Remove the (4) plastic clips from the bottom side of the cover panel.
Step 3. Attach the (4) plastic clips (removed in step 2) to the new metal Dash cover
panel.
Step 4. Attach the metal dash cover panel using the same bolt that was removed
in step 1. Tighten bolt to a snug fit only. Over torquing will cause the U-Nut to
strip.
Step 5. Remove the (4) 1/4-20 x 1/2" long socket button head machine screws
that hold the top plate on the vehicle specific console box.
Step 6. Attach the main bracket to the vehicle specific console box with the
(4) 1/4-20 x 7/8" long socket button head machine screws provided in the
hardware bag.
3/3
1/4-20 x 7/8" long
socket button head
screws
Main bracket
3/8-16 x 3/4" long
hex bolts and flat
washers
1/4-20 x 1/2" long
socket button head
screws
Clevis
Step 7. Attach the main bracket to the dash cover plate with the 3/8-16 x 3/4"
hex bolts and flat washers provided in the hardware bag.
