TYTO-02
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 6/26/19 INSTTYTO-02
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
OPTIONAL ACCESSORIES (sold separately)
TOOLS REQUIRED
• Cutting tool • Crimping tool • Tape • Connectors
(example: butt-connectors, bell caps, etc.)
TABLE OF CONTENTS
Connections ............................................................2
Installation .............................................................3
Programming .........................................................3
Toyota Amplifier Interface 2012-up
• Provides wires for multimedia radios (park brake, reverse)
•
Designed for amplified systems
• High level speaker input
• Retains balance and fade
• Prewired ASWC-1 harness (ASWC-1 sold separately)
• Pre-wired AX-CUSTOM-BT harness (AX-CUSTOM-BT sold separately)
• Micro-B USB updatable
• TYTO-02 interface • TYTO-02 harness
• 16-pin harness with stripped leads
Steering Wheel Control Interface: ASWC-1
Vehicle Customization Interface: AX-CUSTOM-BT
APPLICATIONS
Toyota
4Runner 2014-up
Avalon 2013-up
Camry (with NAV) 2012-2017
Highlander 2014-up
Prius 3rd gen. (with NAV) 2012-2015
Prius PHV (with NAV) 2012-2015
Prius V 2012-2017
Rav-4 2014.5-2018
Sequoia (with NAV) 2013
Sequoia 2014-up
Sienna 2015-2017
Tacoma 2014-2015
Tundra 2014-up
Venza (with HDD based NAV) 2013-2014
Venza 2015
2
CONNECTIONS
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the wire to the amp turn on wire.Blue/White
• Connect the wire to the right front positive speaker output.Gray
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
• Connect the wire to the radio’s left rear positive speaker output.Green
• Connect the wire to the radio’s left rear negative speaker output.Green/Black
• Connect the wire to the radio’s right rear positive speaker output.Purple
• Connect the wire to the radio’s right rear negative speaker output.Purple/Black
• Tape off and disregard the following (6) wires, they will not be used in this application:
Brown Light Green Blue/Pink Green/Purple Orange/White, , , , , Red
From the TYTO-02 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
The following (2) wires are only for multimedia/navigation radios that require these wires.
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wireLight Green
• Connect the and RCA jacks to the audio AUX-IN jacks from the aftermarket radio.Red White
12-pin pre-wired ASWC-1 harness & 3.5mm jack
This harness and 3.5mm jack are to be used with the ASWC-1 (sold separately) to retain
steering wheel audio controls. If the ASWC-1 is not being used, disregard this harness &
3.5mm jack. If it will be used, please refer to the ASWC-1 instructions for radio connections and
programming. Disregard the harness that comes with the ASWC-1.
16-pin pre-wired AX-CUSTOM-BT harness
This harness is to be used along with the AX-CUSTOM-BT (sold separately) to retain the
personalization menu that is lost when removing the factory radio. If the AX-CUSTOM-BT is not
being used, disregard this harness. If it will be used, refer to the AX-CUSTOM-BT manual for app
instructions. Disregard the harness that comes with the AX-CUSTOM-BT.
3
REV. 6/26/2019 INSTTYTO-02
With the key in the off position:
Locate the factory radio harness in the vehicle and complete all necessary connections to the 1.
aftermarket radio.
Connect the and the 2. 16-pin harness with stripped leads TYTO-02 harness into the TYTO-02
interface.
Connect the 3. TYTO-02 harness to the factory radio harness in the vehicle.
• Turn the key (or push-to-start button) to the ignition position and wait until the radio comes on.
The factory amplifier should come on and you should hear sound at this point.
• Test all functions of the installation for proper operation, before reassembling the dash.
INSTALLATION PROGRAMMING
