Seite 1/16
APPLICATIONS
METRA. The Worldā€™s best kits.ā„¢metraonline.com1-800-221-0932 Ā© COPYRIGHT 2004-2013 METRA ELECTRONICS CORPORATION
REV. 12/15/2013 INST99-7014
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Installation instructions for 99-7014
ā€¢ī˜ ISOī˜DINī˜radioī˜provisionī˜withī˜pocket
ā€¢ī˜ Doubleī˜DINī˜radioī˜provision
ā€¢ 99-7014B - Painted scratch resistant matte black
ā€¢ 99-7014HG - Painted high gloss black
ā€¢ī˜A)ī˜Radioī˜trimī˜plateī˜ā€¢ī˜B)ī˜Hazardī˜controlī˜boardī˜ā€¢ī˜C)ī˜Doubleī˜DINī˜bracketsī˜ā€¢ī˜D)ī˜Pocketī˜ā€¢ī˜E)ī˜(9)ī˜Panelī˜clipsī˜
ā€¢ī˜F)ī˜(7)ī˜#8ī˜xī˜3/8ā€ī˜Phillipsī˜panī˜headī˜screwsī˜ā€¢ī˜G)ī˜(4)ī˜#8ī˜xī˜3/8ā€ī˜Phillipsī˜trussī˜headī˜screwsī˜ī˜ ī˜
ā€¢ī˜H)ī˜(3)ī˜#4ī˜xī˜3/8ā€ī˜Phillipsī˜panī˜headī˜screws
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONSī˜(soldī˜separately)
Wiringī˜Harness:
ā€¢ī˜70-7005ī˜-ī˜Mitsubishiī˜harnessī˜2007-up
ā€¢ī˜MITO-02ī˜-ī˜(2011-2013ī˜models)
ā€¢ī˜MITO-03ī˜-ī˜(2014ī˜models)
Antennaī˜Adapter:
ā€¢ī˜Notī˜required
ā€¢ī˜Panelī˜removalī˜toolī˜ā€¢ī˜Phillipsī˜screwdriverī˜
ā€¢ī˜Socketī˜set
TOOLS REQUIRED
See application list inside
AB C D E
FG H
99-7014
Dash Disassembly
ā€“ī˜ Mitsubishiī˜Outlanderī˜Sportī˜2011-2014ī˜...........................................................2-4
Kit Assembly
ā€“ī˜ Radioī˜trimī˜panelī˜assemblyī˜................................................................................. 5
ā€“ī˜ ISOī˜DINī˜radioī˜provisionī˜withī˜pocketī˜.................................................................... 6
ā€“ī˜ Doubleī˜DINī˜radioī˜provisionī˜................................................................................. 7
Table of Contents
1.ī˜ Gentlyī˜pryī˜theī˜radioī˜controlī˜
panelī˜fromī˜theī˜dash.ī˜
Disconnectī˜theī˜harnessī˜andī˜
placeī˜panelī˜aside.ī˜ī˜(Figureī˜A)
2.ī˜ Removeī˜(4)ī˜Phillipsī˜screwsī˜
securingī˜theī˜radioī˜chassisī˜
toī˜theī˜subī˜dashī˜andī˜removeī˜
radio.ī˜ī˜(Figureī˜B)
ī˜Continued on next page
Mitsubishi Outlander Sport 2011-2014
(Figure B)
(Figure A)
Dash Disassembly 99-7014
3.ī˜ Removeī˜(4)ī˜Phillipsī˜screwsī˜securingī˜silverī˜trimī˜panelsī˜toī˜radioī˜controlī˜panelī˜
andī˜placeī˜asideī˜forī˜kitī˜assembly.ī˜ī˜(Figureī˜C)
4.ī˜ Removeī˜(16)ī˜#1ī˜Phillipsī˜screwsī˜securingī˜theī˜circuitī˜boardī˜toī˜theī˜radioī˜controlī˜
panel.ī˜Placeī˜(2)ī˜screwsī˜asideī˜forī˜laterī˜inī˜kitī˜assembly.ī˜ī˜(Figureī˜D)
ī˜Continued on next page
Mitsubishi Outlander Sport 2011-2014
(Figure C) (Figure D)
