AXBUCS-MZ286V
INSTALLATION INSTRUCTIONS
AXBUCS-MZ286V
INSTALLATION INSTRUCTIONS
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
AXBUCS-MZ286V
AXBUCS-MZ286V
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INSTRUCCIONES DE INSTALACN
INSTRUCCIONES DE INSTALACIÓN
INTERFACE FEATURES
Pre-wired AXSWC harness (AXSWC sold separately)
Retains the factory backup camera
Includes the AXCSD-6V 12-volt to 6-volt converter
INTERFACE COMPONENTS
AXBUCS-MZ286V harness • AXCSD-6V 12-volt to 6-volt converter
AXBUCS-MZ286V
Mazda (with center display screen)
2014-Up*
APPLICATIONS
MAZDA
CX-3 2016-Up
CX-5 2017-Up
Mazda3 2014-Up
Mazda6 2016-Up
MX-5 2016-Up
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
CARACTERÍSTICAS DE LA INTERFASE
Arnés AXSWC precableado (el AXSWC se vende por separado)
Retiene la cámara de reversa de fábrica
Incluye el AXCSD-6V de 12 voltios al convertidor de 6 voltios
COMPONENTES DE LA INTERFASE
Arnés AXBUCS-MZ286V • AXCSD-6V de 12 voltios al convertidor de 6 voltios
AXBUCS-MZ286V
Mazda (con pantalla central)
2014 y mas*
APLICACIONES
* Visite AxxessInterfaces.com para aplicaciones específicas de vehículos actualizadas.
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente las luces del
indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no quite el radio de fábrica
con la llave en la posición o de encendido ni con el vehículo funcionando.
CARACTERÍSTICAS DE LA INTERFASE
Arnés AXSWC precableado (el AXSWC se vende por separado)
Retiene la cámara de reversa de fábrica
Incluye el AXCSD-6V de 12 voltios al convertidor de 6 voltios
COMPONENTES DE LA INTERFASE
Arnés AXBUCS-MZ286V • AXCSD-6V de 12 voltios al convertidor de 6 voltios
AXBUCS-MZ286V
Mazda (con pantalla central)
2014 y mas*
* Visite AxxessInterfaces.com para aplicaciones específicas de vehículos actualizadas.
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente las luces del
indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no quite el radio de fábrica
con la llave en la posición o de encendido ni con el vehículo funcionando.
INTERFACE FEATURES
Pre-wired AXSWC harness (AXSWC sold separately)
Retains the factory backup camera
Includes the AXCSD-6V 12-volt to 6-volt converter
INTERFACE COMPONENTS
AXBUCS-MZ286V harness • AXCSD-6V 12-volt to 6-volt converter
AXBUCS-MZ286V
Mazda (with center display screen)
2014-Up*
APPLICATIONS
MAZDA
CX-3 2016-Up
CX-5 2017-Up
Mazda3 2014-Up
Mazda6 2016-Up
MX-5 2016-Up
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
MAZDA
CX-3 2016 y mas
CX-5 2017 y mas
Mazda3 2014 y mas
Mazda6 2016 y mas
MX-5 2016 y mas
APLICACIONES
MAZDA
CX-3 2016 y mas
CX-5 2017 y mas
Mazda3 2014 y mas
Mazda6 2016 y mas
MX-5 2016 y mas
AXBUCS-MZ286V
INSTALLATION INSTRUCTIONS
AXBUCS-MZ286V
INSTALLATION INSTRUCTIONS
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
AXBUCS-MZ286V
AXBUCS-MZ286V
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
REV. 1/24/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INSTRUCCIONES DE INSTALACN
INSTRUCCIONES DE INSTALACIÓN
K PNOWLEDGE IS OWER
Enhance your installat ion and fabricat ion skills by
enrolling in the most recognized and spect ed re
mobile elect nics school in our indust ry.ro
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a bett er tomorrow.
®
Metra recommends MECP
certified technicians
Connections to be made
Connect the
Black
wire to chassis ground, and also to the
Black
wire of the AXCSD-6V.
Connect the
Red
wire labeled "Camera Power 6V" to the
Blue/Red
wire of the AXCSD-6V.
Connect the
Red
wire labeled (AXSWC 12v accessory) and the
Blue/White
wire from the
AXCSD-6V to accessory power.
To the aftermarket radio:
Connect the
Yellow
RCA jack to the backup camera input.
Installing the AXBUCS-MZ286V
With the key in the off position:
After the radio has been tested and working, connect the AXBUCS-MZ286V harness to the vehicle,
and then into the AXSWC.
Refer to the AXSWC instructions for radio connections and programming.
Note:
Disregard the harness that comes with the AXSWC.
K PNOWLEDGE IS OWER
Enhance your installat ion and fabricat ion skills by
enrolling in the most recognized and spect ed re
mobile elect nics school in our indust ry.ro
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a bett er tomorrow.
®
Metra recommends MECP
certified technicians
Connections to be made
Connect the
Black
wire to chassis ground, and also to the
Black
wire of the AXCSD-6V.
Connect the
Red
wire labeled "Camera Power 6V" to the
Blue/Red
wire of the AXCSD-6V.
Connect the
Red
wire labeled (AXSWC 12v accessory) and the
Blue/White
wire from the
AXCSD-6V to accessory power.
To the aftermarket radio:
Connect the
Yellow
RCA jack to the backup camera input.
Installing the AXBUCS-MZ286V
With the key in the off position:
After the radio has been tested and working, connect the AXBUCS-MZ286V harness to the vehicle,
and then into the AXSWC.
Refer to the AXSWC instructions for radio connections and programming.
Note:
Disregard the harness that comes with the AXSWC.
Conexiones que se deben hacer
Conecte el cable a la tierra del chasís y también al alambre negro negro del AXCSD-6V.
Conecte el cable
rojo
con la etiqueta "Camera Power 6V" al cable
azul/rojo
del AXCSD-6V
.
Conecte el cable
rojo
etiquetado (accesorio AXSWC 12v) y el cable
azul/blanco
del AXCSD-6V a la
corriente de accesorios.
Al radio de mercado secundario:
Conecte el conector RCA a la entrada de la cámara de reversa.amarillo
Instalación del AXBUCS-MZ286V
Con la llave en la posición de apagado:
Después de que se haya probado el radio y que esté funcionando, conecte el arnés AXBUCS-
MZ286V al vehículo y luego al AXSWC.
Consulte las instrucciones de AXSWC para las conexiones del radio y la programación.
Nota:
Ignore el arnés que viene con el AXSWC.
Conexiones que se deben hacer
Conecte el cable a la tierra del chasís y también al alambre negro negro del AXCSD-6V.
Conecte el cable
rojo
con la etiqueta "Camera Power 6V" al cable
azul/rojo
del AXCSD-6V
.
Conecte el cable
rojo
etiquetado (accesorio AXSWC 12v) y el cable
azul/blanco
del AXCSD-6V a la
corriente de accesorios.
Al radio de mercado secundario:
Conecte el conector RCA a la entrada de la cámara de reversa.amarillo
Instalación del AXBUCS-MZ286V
Con la llave en la posición de apagado:
Después de que se haya probado el radio y que esté funcionando, conecte el arnés AXBUCS-
MZ286V al vehículo y luego al AXSWC.
Consulte las instrucciones de AXSWC para las conexiones del radio y la programación.
Nota:
Ignore el arnés que viene con el AXSWC.
®Metra recomienda técnicos
con certificación del Programa
de Certificación en Electrónica
Móvil (Mobile Electronics
Certification Program, MECP).
EL CONOCIMIENTO ES PODER
Mejore sus habilidades de instalación y
fabricación inscribiéndose en la escuela de
disposit ivos electnicos móviles más reconocida
y respetada de nuestra industria. Regístrese en
www.installerinstitute.com o llame al
800-354-6782 para obtener más información y
avance hacia un futuro mejor.
®Metra recomienda técnicos
con certificación del Programa
de Certificación en Electrónica
Móvil (Mobile Electronics
Certification Program, MECP).
EL CONOCIMIENTO ES PODER
Mejore sus habilidades de instalación y
fabricación inscribiéndose en la escuela de
disposit ivos electnicos móviles más reconocida
y respetada de nuestra industria. Regístrese en
www.installerinstitute.com o llame al
800-354-6782 para obtener más información y
avance hacia un futuro mejor.
