© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 5/19/20
axxessinterfaces.com • metraonline.com
Axxess Integrate
Installation Instructions for AXBUCS-NI246V
INTERFACE FEATURES
• Pre-wired AXSWC harness (AXSWC sold separately)
• Retains the factory AUX-IN jack
• Retains the factory backup camera to an aftermarket radio*
• Includes the AXCSD-6V 12-volt to 6-volt converter
* Will not work with models equipped with an "All Around Camera" system
AXBUCS-NI246V
Nissan (with NAV) 2011-Up
INTERFACE COMPONENTS
AXBUCS-NI246V harness • AXCSD-6V 12-volt to 6-volt converter
Wire cutter • Crimping tool • Solder gunTape
• Connectors (example: butt connectors, bell caps, etc.)
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
NISSAN
Altima 2013-Up
Cube
2011-2014*
Frontier 2013-Up*
Juke 2011-2014*
NV 2012-Up*
NV200 2012-Up*
Rogue (w/ Bose)
2012-2013*
Rogue 2011*
Sentra 2011-Up*
Titan 2013-2015*
Versa 2013-Up*
Xterra
2013-2015*
APPLICATIONS
* For use when retaining the OE backup camera only
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 5/19/20
axxessinterfaces.com • metraonline.com
Axxess Integrate
Installation Instructions for AXBUCS-NI246V
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most cognized and spect ed re re
mobile electronics s chool in our industry.
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo information a nd t ake st eps re
toward a bett er t omorrow.
Metra r ecommends MECP
certified technicians
Connections to be made
Connect the wire with a ring terminal to chassis ground.Black
Connect the wire of the AXCSD-6V wire to chassis ground.Black
• Connect the wire labeled "Camera Power 6V" to the wire Red Blue/Red
of the AXCSD-6V.
Connect the wire to the reverse wire of the aftermarket radio, Green/Purple
and also to the wire of the AXCSD-6V.Blue/White
For all models except the Cube / Rogue, if retaining the factory AUX-IN jack,
connect the & RCA jacks to the AUX input.Red White
• Connect the Yellow RCA jack to the rear camera input of the aftermarket radio
.
12-pin pre-wired AXSWC harness:
This harness is to be used along with the optional AXSWC (not included) to
retain steering wheel audio controls. Please refer to the AXSWC instructions
for radio connections and programming.
Note: Disregard the harness that comes with the AXSWC.
• Connect the unlabeled wire to the accessory wire.Red
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 5/19/20
axxessinterfaces.com • metraonline.com
Axxess Integrate
Instrucciones de instalación para AXBUCS-NI246V
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no
quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
CARACTERÍSTICAS DE LA INTERFASE
Arnés AXSWC precableado (el AXSWC se vende por separado)
• Retiene el conector de de labrica AUX-IN
• Retiene la cámara de reversa de fábrica de mercado secundario*
• Incluye el AXCSD-6V 12 voltios al convertidor de 6 voltios
* No funciona con los modelos equipados con un sistema de "todo alrededor
de la cámara"
AXBUCS-NI246V
Nissan (con NAV) 2011 y Mas
COMPONENTES DE LA INTERFASE
Arnés AXBUCS-NI246V • AXCSD-6V 12 voltios al convertidor de 6 voltios
• Cortacables • Ponchadora • Pistola soldadora • Cinta
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
HERRAMIENTAS REQUERIDAS
NISSAN
Altima 2013ymas
Cube 2011-2014*
Frontier
2013 y Mas*
Juke 2011-2014*
NV 2012 y Mas*
NV200
2012 y Mas*
Rogue (con Bose)
2012-2013*
Rogue 2011*
Sentra 2011yMas*
Titan 2013-2015*
Versa
2013 y mas*
Xterra
2013-2015*
APPLICATIONS
* Para usar cuando la cámara de OE se va a retener
