Seite 1/8
AXTO-TY1
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 1/3/22 INSTAXTO-TY1
Attention: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
NOTE: Refer to the instructions included with
the aftermarket radio.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip-ties
• Small flat-blade screwdriver
TABLE OF CONTENTS
Connections .........................................................2-3
Installation .............................................................3
Programming .........................................................3
Audio level adjustment .........................................3
Wiring diagram ......................................................4
Toyota Digital Amplifier Interface 2001-2015
• Designed for amplified models
• Retains balance and fade
• USB Micro-B updatable
• AXTO-TY1 harness
• AXTO-TY1 interface
• 16-pin harness with stripped leads
APPLICATIONS
See inside front cover
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
2
APPLICATIONS CONNECTIONS
LEXUS
ES Series 2007-2012
ES Series (w/ multi disc) 2002-2006
GS Series 2001-2005
IS Series 2002-2005
LS Series 2001-2006
RX Series 2004-2009
SC Series 2002-2010
TOYOTA
4-Runner 2003-2013
Avalon 2005-2010
Avalon 2011-2012
(Camry) Solara 2004-2008
Camry (w/o nav) 2012-2013
Camry 2007-2011
Corolla 2003-2011
TOYOTA (Cont.)
FJ Cruiser 2011-2014
Highlander 2008-2013
Highlander Hybrid 2008-2012
Matrix 2005-2012
Prius 3rd Gen (w/o nav) 2012-2015
Plug-In (PHV) (w/o nav) 2012-2015
Prius 2004-2011
Rav-4 2004-2014.5
Sequoia 2005-2012
Sequoia (w/o nav) 2013
Sienna 2004-2014
Tacoma 2005-2013
Tundra 2006-2013
Tundra (Double Cab) 2004-2005
Venza (w/ SD card based nav) 2013-2014
Venza 2009-2012
From the 16-pin harness with stripped leads to the aftermarket radio, connect as indicated:
• wire to the left front (+) speaker output.White
• wire to the left front (-) speaker output.White/Black
• wire to the right front (+) speaker output.Gray
• Gray/Black wire to the right front (-) speaker output.
• wire to the radio’s left rear (+) speaker output.Green
• wire to the radio’s left rear (-) speaker output.Green/Black
• wire to the radio’s right rear (+) speaker output.Purple
• wire to the radio’s right rear (-) speaker output.Purple/Black
• wire to the amplifier turn on wire. Blue/White
Note: This wire must be connected to hear sound from the factory amplifier.
• Tape off and disregard the following (6) wires, they will not be used in this application:
Red, , , , Brown Light Green Blue/Pink Green/Purple Orange/White,
Continued on the next page
3
REV. 1/3/22 INSTAXTO-TY1
From the AXTO-TY1 harness to the aftermarket radio, connect as indicated:
• wire to the ground wire.Black
• Yellow wire to the battery wire.
• wire to the accessory wire.Red
• wire to the power antenna wire.Blue
• wire to the illumination wire. (if applicable)Orange
• wire connect this to the ground wire if there is noise in the system. Black/White
With the key in the off position:
1. Connect the , and the 16-pin harness with stripped leads AXTO-TY1 harness into the
AXTO-TY1 interface.
2. Connect the AXTO-TY1 harness to the wiring harness in the vehicle.
1. With the vehicle and radio turned on, turn the volume up 3/4 of the way.
2. With a small flat-blade screwdriver, adjust the potentiometer clockwise to raise the audio
level; counter clockwise to lower the audio level.
3. Once at a desired level, audio adjustment is complete.
1. Turn the key (or push-to-start button) to the ignition position and wait until the radio
comes on. The factory amplifier should come on and you should hear sound at this point.
2. Test all functions of the installation for proper operation, before reassembling the dash.
Note: To ensure that balance and faders are centered, turn volume up 3/4 and shut off vehicle
DO NOT shut off the radio, prior to shutting off the vehicle.
CONNECTIONS (CONT.) PROGRAMMING
AUDIO LEVEL ADJUSTMENTINSTALLATION
