INSTALLATION INSTRUCTIONS FOR PART HYBL-05
METRA. The World’s best kits.™metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
REV. 7/24/2013 INSTHYBL-05
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• RetainsfactoryBluelink
• Providesnavigationoutputs
• USBupdatable
• Retainsfadeandbalance
• Usedinnon-amplifiedsoundsystems
• Retainsfactorybackupcamera
• Retainsfactory3.5mmjack
• Highlevelspeakerinput
• PrewiredASWC-1harnessincluded(ASWC-1soldseparately)
KIT FEATURES
•Cuttingtool•Crimpingtool•Tape•Connectors
(example:butt-connectors,bellcaps,etc.)
TOOLS REQUIRED
Hyundai Veloster Blue Link interface
2011-up
APPLICATIONS
•HYBL-05Interface•16-pinharnesswith
strippedleads•18-pinto24-&18-pinconnector
INTERFACE COMPONENTS
HYUNDAI
Veloster 2011-up
HYBL-05
• Connectthe wiretothegroundwireoftheaftermarketradio.Black
• Connectthe wiretothepowerantennawireoftheaftermarketBlue  
radio.Iftheaftermarketradiodoesnothaveapowerantennawiretape
offthe wire.Blue
• Connectthe wiretotheilluminationwireoftheaftermarketradio.Orange
Iftheaftermarketradiohasnoilluminationwire,tapeoffthe wire.Orange
• Connectthe wiretotheparkingbrakewireoftheaftermarketLight Green
navigationradio.
• Co
nnectthe and RCAtotheaftermarketradiosAUXinput.White Red
From the 2nd 24-pin harness:
• ConnecttheYellowRCAtothevideoinoftheaftermarketradio.
From the 18-pin harness:
• Connectthe wiretotheVSSorspeedsensewireoftheaftermarketBlue/Pink
navigationradio.
• Connectthe wiretothereversewireoftheaftermarketGreen/Purple
navigationradio.
• Connectthe wiretotheradio’sleftrearpositivespeakeroutput.Green
• Connectthe wiretotheradio’sleftrearnegativespeakeroutput.Green/Black
From the 16-pin harness with stripped leads:
• Connectthe wirestotheignitionwireoftheaftermarketradio.Red
• Connectthe wiretotheleftfrontpositivespeakeroutputoftheWhite
aftermarketradio.
• Connectthe wiretotheleftfrontnegativespeakeroutputoftheWhite/Black
aftermarketradio.
• Connectthe wiretotherightfrontpositivespeakeroutputoftheGray
aftermarketradio.
• Connectthe wiretotherightfrontnegativespeakeroutputoftheGray/Black
aftermarketradio.
• Connectthe wiretothemutewireoftheaftermarketradio.IftheBrown
aftermarketradiodoesnothaveaMutewire,tapeupthe wire.Brown
• The willnotbeusedinthisapplication.Blue/Pink
• The wirewillnotbeusedinthisapplication.Green/Purple
• The wirewillnotbeusedinthisapplication.Orange/White
• The wirewillnotbeusedinthisapplication.Light Green
From the 1st 24-pin harness:
• ConnecttheYellowwiretothe12-voltconstant/batterywireof 
theaftermarketradio.
Connections to be made
HYBL-05
Connections to be made
• Connectthe wiretotheradio’srightrearpositivespeakeroutput.Purple
• Connectthe wiretotheradio’srightrearnegativePurple/Black  
speakeroutput.
Testing and adjusting the HYBL-05
1. Turntheaftermarketradioon.
2. Setpotentiometerallthewaytotheleft.
3. Setradiotodesiredlevel.
4. Adjustthepotentiometertotherightuntiltheradio’saudiolevelishigh
andfreeofdistortion.
5. TestBlueLink.
6. Reassembledashandenjoyyournewradio.
Additional 12-pin harness (ASWC-1 harness)
This12-pinharnessistobeusedinconjunctionwiththeASWC-1(notincluded).
PleaserefertoASWC-1instructionsforprogramming.
Installing the HYBL-05
Installing the HYBL-05
1. Withalltheconnectionscompleted,plugthe16-and18-pinharnesses
intotheHYBL-05.
2. Plugthe24-&18-pinharnessintothevehiclesideharness,andplugthe
aftermarketradioharnessintotheaftermarketradio.
3. Reconnectthenegativebatteryterminal.
4. Turntheignitionon,butdonotstartthecar.
5. Pressandholdthevolumeupbuttononthesteeringwheelfor5-seconds,
thiswilllearnBlueLink.
6. Ifthevehiclecameequippedwithfactorynavigationpressandholdthemode
buttononthesteeringwheelfor5-seconds(Ifvehicledidnotcomeequipped
withfactorynavigation,skipthisstep).
Installing the HYBL-05
