Seite 1/4
METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
Installation Instructions for GMRC-03
REV. 11/14/2013 INSTGMRC-03
(continued on next page)
GMRC-03
GM Class II data bus interface
1996-2002
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power), if equipped
• Used in non-amplified systems or when replacing amplified systems
• Retains all warning chimes through onboard speaker
KIT FEATURES
• GMRC-03 data interface
• 10-pin to 24-pin GM harness with stripped leads
INTERFACE COMPONENTS
• Cutting tool • Crimping tool • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
CADILLAC
Catera 1997-2001
Deville 1996-1999
Eldorado 1996-2002
Seville 1996-1999
APPLICATIONS
CONNECTIONS TO BE MADE
From the 10-pin harness:
• Connect the Yellow wire to the to the radio’s 12-volt battery or memory wire.
• Connect the wire to the radio’s 12-volt accessory or switched wire.Red
• Connect the wire to the radio’s ground wire.Black
• When completed plug the 10-pin harness into the GMRC-03.
From the 32-pin harness:
• Connect the wire to the radios antenna turn-on wire. If no antenna turn-on Blue
wire is present, hook wire to the radios amplifier turn-on wire.Blue
• Connect the wire to the radio’s dimmer wire. If your radio does Orange/White
not have a dimmer wire, just tape off wire.
• Connect the wire to the radios left front positive speaker output.White
• Connect the wire to the radio’s left front negative speaker output.White/Black
• Connect the wire to the radio’s left rear positive speaker output.Green
• Connect the wire to the radio’s left rear negative speaker output.Green/Black
• Connect the wire to the radio’s right front positive speaker output.Gray
• Connect the wire to the radio’s right front negative Gray/Black
speaker output.
• Connect the wire to the radio’s right rear positive speaker output.Purple
• Connect the wire to the radio’s right rear negative Purple/Black
speaker output.
GMRC-03
METRA. The World’s best kits.metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
K PNOWLEDGE IS OWER
Enhance your inst allation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better t omorrow.
Metra recommends MECP
certified technicians
Note: If the chime volume of the GMRC-03 is too loud you will need to remove the cover and
cut the solder connection where the arrow points to on the circuit board (between the holes
on the board).
Cut for low volume
installinG the Gmrc-03
• With all connections completed to the aftermarket radio, plug the 32-pin
harness into the vehicles wiring harness.
• Reconnect the negative battery terminal.
• Cycle the key by turning the ignition on for 30 seconds. Then off and on again
to test the radio.
• Mount the GMRC-03 in a location where the internal speaker will be heard.
METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
Instrucciones de instalación para GMRC-03
REV. 11/14/2013 INSTGMRC-03
(continúa en la página)
GMRC-03
GM Class II data bus interface
1996-2002
• Proporciona accesorio (12-voltios 10-amperes)
• Retiene R.A.P. (Corriente de accesorio retenida)
• Usado en sistemas no amplificados o cuando se reemplazan los
sistemas amplificados
• Retiene todos los tonos de advertencia mediante la bocina incluida
CARACTERÍSTICAS DEL KIT
• Interfase de datos GMRC-03
Arnés GM de 10-pins a 24-pins con contactos desnudos
COMPONENTES DE LA INTERFASE
• Cortador • Pelacables • Cinta • Conectores
(p. ej., conectores a tope, tapas acampanadas, etc.)
HERRAMIENTAS REQUERIDAS
CADILLAC
Catera 1997-2001
Deville 1996-1999
Eldorado 1996-2002
Seville 1996-1999
APLICACIONES
CONEXIONES QUE SE DEBEN HACER
Desde el ars de 10 pins:
• Conecte el cable con la batería de 12 voltios o el cable de memoria amarillo
del radio.
• Conecte el cable al cable de accesorios de 12 voltios o al cable rojo
conmutado.
• Conecte el cable con el cable de puesta a tierra del radio.negro
• Cuando termine, conecte el arnés de 10 pins en el GMRC-03.
Desde el ars de 32 pins:
• Conecte el cable con el cable de encendido de la antena. Si no hay azul
cable de encendido de la antena presente, conecte el cable azul al cable de
encendido del amplificador del radio.
• Conecte el cable con el cable atenuador del radio. Si su anaranjado/blanco
radio no tiene un cable atenuador, solo encinte el cable.
• Conecte el cable con la salida de la bocina positiva izquierda del blanco
frente del radio.
• Conecte el cable con la salida de la bocina negativa izquierda blanco/negro
del frente del radio.
• Conecte el cable con la salida de la bocina positiva izquierda de verde
atrás del radio.
• Conecte el cable con la salida negativa de la bocina izquierda verde/negro
de atrás del radio.
Conecte el cable con la salida positiva de la bocina derecha del frente del radio. gris
• Conecte el cable con la salida de la bocina negativa derecha del gris/negro
frente del radio.
• Conecte el cable con la salida positiva de la bocina derecha de púrpura
atrás del radio.
• Conecte el cable con la salida negativa de la bocina derecha púrpura/negro
de atrás del radio.
