AXVT
IN STALLATION IN STR UC TI ON S
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
• Provides 12-volts DC output when voltage is at or above 13.5-volts DC
• Designed for vehicles that do not provide accessory (switched) power
• 10-amp fuse included for safety
• Provides accessory power (13.5-volts 10-amps)
• Delayed turn-off after vehicle has been turned off
INTERFACE FEATURES
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
• Connect the wire to chassis ground.Black
• Connect the Yellow wire to battery power.
• Connect the wire to the aftermarket device's accessory (switched) power wire.Red
TOOLS REQUIRED
CONNECTIONS TO BE MADE
AXVT Accessory Provider
CAUTION! All accessories, switches, climate controls panels, and especially air bag
indicator lights must be connected before cycling the ignition. Also, do not remove
the factory radio with the key in the on position, or while the vehicle is running.
AXVT
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INST RUCCIONES DE INSTALACIÓN
• Proporciona una salida de DC de 12 voltios cuando el voltaje es igual o superior
a 13.5 voltios DC
• Diseñado para vehículos que no proporcionan energía accesoria (conmutada)
• Fusible de 10 amperios incluido para seguridad
• Proporciona energía accesoria (13.5-voltios 10-amperios)
• Apagado demorado después de que el vehículo se apagó
CARACTERÍSTICAS DE LA INTERFAZ
• Herramienta de engarzado y conectores, o pistola de soldadura, soldadura y
termocontracción • Cinta • Cortador de alambre • Lazos de cremallera
• Conecte el cable negro a la tierra del chasís.
• Conecte el cable amarillo a la alimentación de la batería.
• Conecte el cable rojo al cable de alimentación accesorio (conmutado) del dispositivo
de recambio.
HERRAMIENTAS REQUERIDAS
CONEXIONES QUE SE DEBEN HACER
Proveedor de accesorios AXVT
¡PRECAUCIÓN! Todos los accesorios, interruptores, paneles de control del clima
y especialmente las luces indicadoras del airbag deben estar conectadas antes
de encender el encendido. Además, no retire la radio de fábrica con la llave en la
posición de encendido o mientras el vehículo esté en funcionamiento.
