METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Installation Instructions for AXVRI
REV. 2/3/2020 INSTAXVRI
AXVRI
Voltage Retention Interface
CONNECTIONS TO BE MADE
From the 8-pin harness to the vehicle-side harness:
Connect the (3) wires to the ground wire.Black
Connect the Yellow fused wire to the battery wire.
Connect the fused wire to the accessory wire.Red
From the 6-pin harness to the aftermarket radio:
Connect the (2) wires together, then connect them to Black/White
the ground wire.
Connect the (2) Yellow/White wires together, then connect them to the
battery wire.
Connect the (2) wires together, then connect them to the Red/White
accessory wire.
Note: Each individual line is rated at 5-amps per line (10-amps
combined total). If each line is going to be used for separate sources--
or the current will surpass 10-amps--please use a relay, Metra part
number E-123 to increase current.
Caution: Metra recommends disconnecting the negative battery terminal before beginning
any installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
*Note: Refer also to the instructions included with the aftermarket radio.
INTERFACE COMPONENTS
AXVRI Interface • 8-pin harness with stripped leads and fuses
• 6-pin harness with stripped leads
TOOLS REQUIRED
• Cutting tool • Tape • Crimping tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
FEATURES
Provides 12-volt output when voltage drops below 7-volts
Designed for vehicles that drop voltage while stopped
Fuses included for safety
Provides accessory power (12-volt 10-amp)
AXVRI
METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
K PNOWLEDGE IS OWER
Enhance your inst allation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take stepsre
toward a better t omorrow.
Metra recommends MECP
certified technicians
IMPORTANT WARNING
This product includes instructions for installation which must be carefully followed. The
instructions are worded in such a manner to assume that the installer is capable of
completing these type of electronic installations. If you are unclear as to what you are
instructed to do or believe that you do not understand the instructions so as to properly
and safely complete the installation you should consult a technician who does have this
knowledge and understanding.
Failure to follow these instructions carefully and to install the interface as described
could cause harm to the vehicle or to safety systems on the vehicle. Interference with
certain safety systems could cause harm to persons as well. If you have any questions
in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
Installation Instructions for AXVRI
REV. 2/3/2020 INSTAXVRI
METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
AXVRI
Interfase de retención de voltaje
CONEXIONES QUE SE DEBEN HACER
Del arnés de 8 pins al arnés del lado del vehículo:
Conecte los (3) cables con el cable de tierra.negros
Conecte el cable con fusible al cable de la batería.amarillo
Conecte el cable con fusible con el cable de accesoriosrojo
Del arnés de 6 pins al radio de mercado secundario:
Conecte los (2) cables entre sí, luego conéctelos con el negros/blancos
cable de tierra.
Conecte los (2) cables entre sí, luego conéctelos con el amarillos/blancos
cable de la batería.
Conecte los (2) cables entre sí, luego conéctelos con el cable rojos/blancos
de accesorios.
Nota: Cada línea está calificada a 5 amperes por línea (10 amperes total
combinado). Si cada línea se utilizará para fuentes independientes o si la
corriente excederá 10 amperes, utilice un relevador, número de parte Metra
E-123 para aumentar la corriente.
Precaución: Metra recomienda desconectar la terminal negativa de la batería antes
de iniciar cualquier instalación. Todos los accesorios, interruptores y especialmente las luces
del indicador de las bolsas de aire deben estar conectados antes de reconectar la batería
o ciclar la ignición.
*Nota: También consulte las instrucciones incluidas con el radio de mercado secundario
COMPONENTES DE LA INTERFASE
• Interfase AXVRI • Arnés de 8 pins con conectores pelados y fusibles
Arnés de 6 pins con conectores pelados
HERRAMIENTAS REQUERIDAS
• Cortador • Cinta • Pelacables
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
CARACTERÍSTICAS
Ofrece salida de 12 voltios cuando el voltaje cae a menos de 7 voltios
Diseñado para vehículos cuyo voltaje cae mientras están detenidos
Se incluyen fusibles para seguridad
Provee corriente de accesorios (12 voltios 10 amperes)
