AXVI-FD3
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com Š COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 2/21/23 INSTAXVI-FD3
Product Info
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties • Multimeter tester
Ford Data Interface 2019-Up
• Provides accessory power (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
•
Provides illumination, parking brake, reverse, and speed sense outputs
• Prewired AXSWC harness (AXSWC sold separately)
• Designed for non-amplified models only
• Retains balance and fade
• Micro-B USB updatable
Note: The AXVI-FD3 does not retain SYNC.
• AXVI-FD3 Interface
• AXVI-FD3 Harness
TABLE OF CONTENTS
Connections ............................................................2
Installation .............................................................3
Programming .........................................................3
APPLICATIONS
Ford
E Series ...........................2021-Up
Eco Sport ........................2020-Up
Escape ............................2020-Up
F250/F350/F450/F550 ...2020-Up
Transit ............................2020-Up
Transit Connect ...............2019-Up
Visit AxxessInterfaces.com for more detailed
information about the product and up-to-date
vehicle specic applications.
2
Front
Rear
Sub
AUX-IN
Rear View
SWC
Aftermarket Radio
This is to be done only in the Ford
Transit/Transit Connect 2019-Up
without SYNC. tain backup To re
camera in an ther application u yo yo
must purchase the AXBUCH-FD1.
12-Pin
Vehicle Connectors
SWC Harness
Steering Wheel
Control (AXSWC)
(Sold Separately)
CENTER
LD- VI-FD3AX
Interface
Red - Accessory po rwe
Orange/White - Illumination (if applicable)
Blue/Pink - S/Speed-SenseVS
Green/Purple - Reverse signal
Light Green - Parking brake
Gray - Front right spea r +ke
Gr /Blackay - Front right speaker -
White - Front left speaker +
White/Black - Front left speaker -
Blue/White - (NOT USED)
Br now - (NOT USED)
Radio Connections
Black - Ground wire
Yellow - Battery wire
Green - Rear left spea r + outputke
Green/Black - Rear left - speaker output
Purple - Rear right + spea r outputke
Purple/Black - Rear right - output
Br e own/Whit (NOT USED)
Blue Ground on Non-SYNC application for reverse camera
From the AXVI-FD3 harness to
the aftermarket radio
CONNECTIONS
3
REV. 2/21/23 INSTAXVI-FD3
INSTALLATION
PROGRAMMING
With the key in the off position:
Connect the 1. AXVI-FD3 harness AXVI-FD3 interface into the , and then to the wiring harness
in the vehicle.
Note: If installing an AXSWC, connect it after you program and test the AXVI-FD3, with the
key in the off position.
Attention! If the interface loses power for any reason, the following steps will need to be
performed again.
Cycle the engine on.1.
Note: If the radio doesn’t come on within 60 seconds, turn the key to the off position,
disconnect the interface, check all connections, reconnect the interface, and then try again.
Cycle the ignition off, then back on.2.
Test all functions of the installation for proper operation.3.
