AXVI-6523
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 10/23/19 INSTAXVI-6523
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
TABLE OF CONTENTS
Connections ............................................................2
Installation .............................................................3
Programming .........................................................3
Chrysler Data Interface 2013-2019
• Provides accessory power
(12-volt 10-amp)
• Retains R.A.P. (retained
accessory power)
• Can be used in both amplified
and non-amplified models
•
Provides NAV outputs (parking
brake, reverse, speed sense)
• Pre-wired AXSWC harness
(AXSWC sold separately)
• Retains the factory backup
camera (if displayed through
the OE radio)
• Retains the 3.5mm AUX-IN jack
• Retains balance and fade
• Micro-B USB updatable
• AXVI-6523 interface
• AXVI-6523 harness
APPLICATIONS
CHRYSLER
200 LX (w/ 3-inch screen) 2015-2016
DODGE
Dart (small screen option) 2013-2016
JEEP
Cherokee Sport 2014-2016
Compass Sport 2017.5-2018
RAM
1500 Classic (w/o touchscreen) 2019
1500/2500/3500 (w/o touchscreen) 2013-2017
Chassis Cab 3500/4500/5500
(w/o touchscreen) 2013-2017
2
CONNECTIONS
From the AXVI-6523 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
If installing an AXSWC (sold separately), there will be an accessory wire there to Note:
connect as well.
• If the vehicle is equipped with a factory amplifier, connect the wire to the amp Blue/White
turn on wire.
• If the aftermarket radio has an illumination wire, connect the wire to it.Orange
• Connect the wire to the right front positive speaker output.Gray
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative speaker output.Purple/Black
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
•
If retaining the factory backup camera, connect the Yellow RCA jack to the backup camera input
.
• If retaining the factory AUX-IN jack, connect the & RCA jacks to the AUX input.Red White
• Tape off and disregard the following (1) wire, will not be used in this application:
Blue/White labeled “500L amp turn on.”
12-pin pre-wired AXSWC harness:
• This harness is to be used along with the optional AXSWC (not included) to retain steering
wheel audio controls. If the AXSWC is not being used, disregard this harness. If it will be
used, please refer to the AXSWC instructions for radio connections and programming.
Disregard the harness that comes with the AXSWC.Note:
• Connect the wire to the accessory wire.Red
3
REV. 10/23/2019 INSTAXVI-6523
INSTALLATION PROGRAMMING
With the key in the off position:
•
Connect the AXVI-6523 harness into the interface, and then to the harness in the vehicle
.
If using the AXSWC, connect it after you initialize and test the AXVI-6523, with the key Note:
in the off position.
Attention! If the interface loses power for any reason, the following steps will need to be
performed again. Also, if installing an AXSWC connect it after you initialize and test the interface/
radio, with the key in the off position.
• Turn the key (or push-to-start button) to the ignition position and wait until the radio comes on.
Note:
If the radio does not come on within 60 seconds, turn the key to the off position,
disconnect the interface, check all connections, reconnect the interface, and then try again.
• Turn the key to the off position, and then to the accessory position. Test all functions of the
installation for proper operation, before reassembling the dash.
