AXVI-6502
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com Š COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 10/11/19 INSTAXVI-6502
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties
TABLE OF CONTENTS
Connections ............................................................2
Chrysler/Dodge Data Interface 2004-2010
APPLICATIONS
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
•
Designed for non-amplied systems
• Provides NAV outputs (parking brake, reverse, speed sense)
• Pre-wired AXSWC harness (AXSWC sold separately)
• Retains balance and fade
• Micro-B USB updatable
CHRYSLER
300 2005-2007
Aspen 2007
PT Cruiser 2006-2010
DODGE
Caliber 2007-2008
Charger 2006-2007
DODGE (CONT)
Dakota 2005-2007
Durango 2004-2007
Magnum 2005-2007
Ram 1500 2006-2008
Ram 2500/3500 2006-2009
Ram Chassis Cab 2008-2010
JEEP
Commander 2006-2007
Compass 2007-2008
Grand Cherokee 2005-2007
Patriot 2007-2008
MITSUBISHI
Raider 2006-2007
• AXVI-6502 Interface
• AXVI-6502 Harness
2
CONNECTIONS
From the AXVI-6502 harness to the aftermarket radio, connect the:
• wire to the ground wire.Black
• Yellow wire to the battery wire.
• wire to the accessory wire.Red
• wire to the power antenna wire.Blue
• wire to the illumination wire (if applicable).Orange
• wire to the front right positive speaker output.Gray
• Gray/Black wire to the front right negative speaker output.
• wire to the front left positive speaker output.White
• wire to the front left negative speaker output.White/Black
• wire to the rear right positive speaker output.Purple
• wire to the rear right negative speaker output.Purple/Black
• wire to the rear left positive speaker output.Green
• wire to the rear left negative speaker output.Green/Black
The following (3) wires are only for multimedia/navigation radios that require these wires.
• wire to the VSS/speed sense wire.Blue/Pink
• wire to the reverse wire.Green/Purple
• wire to the parking brake wireLight Green
12-pin AXSWC harness & 3.5mm jack:
The 12-pin harness & 3.5mm jack is to be used with the (sold separately) AXSWC AXSWC
to retain steering wheel audio controls. If the is not being used, disregard this AXSWC
harness. If it is to be used, refer to the instructions for radio connections and AXSWC
programming. Disregard the harness that comes with the AXSWC.
3
REV. 10/11/2019 INSTXSVI-6502-BNAV
