METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Installation Instructions for AXVI-2105
REV. 8/6/2020 INSTAXVI-2105
(continued on next page)
GM/Suzuki 2006-up
AXVI-2105
GM LAN 29 accessory and NAV output interface
WIRING THE AXVI-2105
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the wire to the radio’s ground wire.Black
• Connect the wire to the ignition wire of the aftermarket radio.Red
• Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the wire to the antenna turn on wire of the aftermarket radio.Blue
• Connect the wire to the left front positive speaker output of the aftermarket radio.White
• Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
• Connect the wire to the right front positive speaker output of the Gray
aftermarket radio.
KIT FEATURES
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
Note: All chimes will be lost when using this harness
BUICK
Enclave 2008-up
Lucerne 2006-2011
CADILLAC
DTS 2006-2011
(only to be used when replacing
an amplified system)
Escalade 2007-2014
(only to be used when replacing
an amplified system)
SRX 2007-2009
(only to be used when replacing
an amplified system)
CHEVROLET
Avalanche 2007-up*
Captiva Sport 2012-up
Cheyenne 2012-up *
Equinox 2007-2009
Express 2008-up
Impala 2006-2013
Impala limited 2014
Monte Carlo 2006-2007
Silverado (new body) 2007-13*
Silverado 2500/3500 2014 *
Suburban 2007-2014*
Tahoe 2007-2014*
Traverse 2009-up
GMC
Acadia 2007-up
Savanna 2008-up
Sierra (new body) 2007-13*
Sierra 2500/3500 2014*
Yukon/XL 2007-2014*
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
Vue 2008-2010
SUZUKI
XL-7 2007-2009
APPLICATIONS
*Non-navigation models only
AXVI-2105
METRA. The World’s best kits.™metraonline.com1-800-221-0932 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 8/6/2020 INSTAXVI-2105
• Connect the wire to the right front negative speaker output of the Gray/Black
aftermarket radio.
• Connect the wire to the radio’s left rear positive speaker output.Green
• Connect the wire to the radio’s left rear negative speaker output.Green/Black
• Connect the wire to the radio’s right rear positive speaker output.Purple
• Connect the wire to the radio’s right rear negative speaker output.Purple/Black
The following wires are for the aftermarket radios that have navigation built in.
• Connect the wire to the parking brake wire of the aftermarket Light Green
navigation radio (if applicable).
• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio (if applicable).
• Connect the wire to the reverse wire of the aftermarket navigation Green/Purple
radio (if applicable).
• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12-pin harness of the
AXVI-2105 and refer to the AXSWC instructions.
K PNOWLEDGE IS OWER
Enhance your inst allation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take stepsre
toward a better t omorrow.
Metra recommends MECP
certified technicians
IMPORTANT WARNING
This product includes instructions for installation which must be carefully followed. The
instructions are worded in such a manner to assume that the installer is capable of
completing these type of electronic installations. If you are unclear as to what you are
instructed to do or believe that you do not understand the instructions so as to properly
and safely complete the installation you should consult a technician who does have this
knowledge and understanding.
Failure to follow these instructions carefully and to install the interface as described
could cause harm to the vehicle or to safety systems on the vehicle. Interference with
certain safety systems could cause harm to persons as well. If you have any questions
in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
