METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Installation Instructions for AXVI-2104
REV. 1/21/2020 INSTAXVI-2104
(continued on next page)
GM 2006-2012
AXVI-2104
GM LAN 11 accessory and NAV output interface WIRING THE AXVI-2104
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the wire to the radio’s ground wire.Black
• Connect the wire to the ignition wire of the aftermarket radio.Red
• Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the Orange wire.
• The Orange/White wire will not be used in this application. Tape up or cap off this
wire and disregard it.
• Connect the wire to the antenna turn on wire of the aftermarket radio.Blue
• Connect the wire to the left front positive speaker output of the aftermarket radio.White
• Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
• Connect the wire to the right front positive speaker output of the Gray
aftermarket radio.
• Connect the wire to the right front negative speaker output of the Gray/Black
aftermarket radio.
• Connect the wire to the radio’s left rear positive speaker output.Green
• Connect the wire to the radio’s left rear negative speaker output.Green/Black
• Connect the wire to the radio’s right rear positive speaker output.Purple
• Connect the wire to the radio’s right rear negative speaker output.Purple/Black
CHEVROLET
Cobalt 2007-2010
HHR 2006-2011
Malibu 2008-2012
PONTIAC
G5 2007-2009
G6 (5th digit of VIN must be a J, K, or L) 2009
G6 2010
Solstice 2006-2009
SATURN
Aura 2007-2009
Sky 2006-2009
APPLICATIONS
KIT FEATURES
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
Note: All chimes will be lost when using this harness
AXVI-2104
METRA. The World’s best kits.™metraonline.com1-800-221-0932 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/21/2020 INSTAXVI-2104
The following wires are for the aftermarket radios that have navigation built in.
• Connect the wire to the parking brake wire of the aftermarket Light Green
navigation radio (if applicable).
• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio (if applicable).
• Connect the wire to the reverse wire of the aftermarket navigation Green/Purple
radio (if applicable).
• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to
test the radio.
AXSWC (if installing)
After the Interface is initialized, plug in the AXSWC into the 12-pin harness of the
AXVI-2104 and refer to the AXSWC instructions.
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take stepsre
toward a better tomorrow.
Metra recommends MECP
certified technicians
IMPORTANT WARNING
This product includes instructions for installation which must be carefully followed. The
instructions are worded in such a manner to assume that the installer is capable of
completing these type of electronic installations. If you are unclear as to what you are
instructed to do or believe that you do not understand the instructions so as to properly
and safely complete the installation you should consult a technician who does have this
knowledge and understanding.
Failure to follow these instructions carefully and to install the interface as described
could cause harm to the vehicle or to safety systems on the vehicle. Interference with
certain safety systems could cause harm to persons as well. If you have any questions
in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
