AXVI-1788
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
FEATURES
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, and speed sense)
Prewired AXSWC harness (AXSWC sold separately)
Retains balance and fade
USB updatable
AXVI-1788
Dodge Sprinter 2008-2009 /
Freightliner Sprinter 2008-up
Accessory and NAV Output CAN Interface
Connections to be made
Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
Connect the wire to the radio’s ground wire.Black
Connect the wire to the ignition wire of the aftermarket radio.Red
Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the wire.Orange
Connect the wire to the antenna turn on wire of the aftermarket radio.Blue
Connect the wire to the left front positive speaker output of the aftermarket radioWhite
.
Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
Connect the wire to the right front positive speaker output of the aftermarket radio.Gray
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator
lights must be connected before cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
AXVI-1788
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most cognized and spect ed re re
mobile electronics s chool in our industry.
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo information a nd t ake st eps re
toward a bett er t omorrow.
Metra r ecommends MECP
certified technicians
Connect the wire to the right front negative speaker output of Gray/Black
the aftermarket radio.
Connect the wire to the radio’s left rear positive speaker output.Green
Connect the wire to the radio’s left rear negative speaker output.Green/Black
Connect the wire to the radio’s right rear positive speaker output. Purple
Connect the wire to the radio’s right rear negative speaker output. Purple/Black
The following (3) wires are for the aftermarket radios that have navigation built in.
Connect the wire to the parking brake wire of the aftermarket Light Green
navigation radio (if applicable).
Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio (if applicable).
Connect the wire to the reverse wire of the aftermarket navigation Green/Purple
radio (if applicable).
INITIALIZING THE AXVI-1788
Attention! If the interface loses power for any reason, the following steps will need to
be performed again. Also, if installing an AXSWC connect it after you initialize and test
the interface/radio, with the key in the off position.
Turn the key (or push-to-start button) to the ignition position and wait until the radio
comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
Turn the key to the off position, and then to the accessory position. Test all functions
of the installation for proper operation, before reassembling the dash.
AXVI-1788
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
CARACTERÍSTICAS
Provee corriente de accesorios (12 voltios 10 amperes)
Retiene R.A.P. (corriente de accesorio retenida)
Proporciona salidas de NAV (freno de mano, reversa y sensor de velocidad
)
Arnés AXSWC pre cableado (el AXSWC se vende por separado)
Retiene el balance y la intensidad
Actualizable mediante USB
Conexiones que se deben hacer
Conecte el cable con la batería de 12 voltios o el cable de memoria del radio. amarillo
Conecte el cable con el cable de puesta a tierra del radio.negro
Conecte el cable con el cable de ignición del radio de mercado secundario.rojo
Conecte el cable con el cable de iluminación del radio de mercado secundario. Si el anaranjado
radio de mercado secundario no tiene cable de iluminación, cubra con cinta el cable .anaranjado
Conecte el cable con el cable de encendido de la antena del radio de mercado secundarioazul
.
Conecte el cable con la salida de la bocina positiva frontal izquierda del radio blanco
de mercado secundario.
Conecte el cable con la salida negativa de la bocina frontal izquierda del blanco/negro
radio de mercado secundario.
Conecte el cable con la salida positiva de la bocina frontal derecha del radio de gris
mercado secundario.
Conecte el cable con la salida negativa de la bocina frontal derecha del gris/negro
radio de mercado secundario.
AXVI-1788
Dodge Sprinter 2008-2009 /
Freightliner Sprinter 2008 y mas
Interfase CAN para accesorios y salida NAV
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además,
no quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
