AXVI-1785
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
AXVI-1785
Mercedes accessory and NAV output CAN Interface 2001-2004
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems, or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING THE AXVI-1785
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the wire to the radio’s ground wire.Black
• Connect the wire to the ignition wire of the aftermarket radio.Red
• Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the wire to the antenna turn on wire of the aftermarket radio.Blue
• Connect the wire to the left front positive speaker output of the White
aftermarket radio.
• Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
MERCEDES
C Class 2001-2004
CLK Class 2004
CLK500 2003
CLK55AMG 2003
AXVI-1785
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
• Connect the wire to the right front positive speaker output of the Gray
aftermarket radio.
• Connect the wire to the right front negative speaker output of the Gray/Black
aftermarket radio.
• Connect the wire to the radio’s left rear positive speaker output.Green
• Connect the wire to the radio’s left rear negative speaker output.Green/Black
• Connect the wire to the radio’s right rear positive speaker output.Purple
• Connect the wire to the radio’s right rear negative speaker output.Purple/Black
The following wires are for the aftermarket radios that have navigation built in.
• Connect the wire to the parking brake wire of the aftermarket Light Green
navigation radio (if applicable).
• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio (if applicable).
• Connect the wire to the reverse wire of the aftermarket navigation Green/Purple
radio (if applicable).
• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12-pin harness of the
AXVI-1785 and refer to the AXSWC instructions.
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most cognized and spected re re
mobile electronics s chool in our industry.
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo informat ion and ta ke steps re
toward a bett er t omorrow.
Metra r ecommends MECP
certified technicians
