Seite 1/4
AXTC-VW2
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 5/9/23 INSTAXTC-VW2
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties
TABLE OF CONTENTS
Connections 2 ............................................................
Programming 3 .........................................................
Troubleshooting.....................................................4
Volkswagen SWC (Steering Wheel Control)
and Data Interface 2015-Up
APPLICATIONS
•
Provides accessory power
(10-amp)
• Provides wires for multimedia
radios (park brake, reverse,
speed sense)
• Designed for non-amplified
models only
• Retains audio controls on the
steering wheel
• Designed to be compatible
with all major radio brands
• Auto detects vehicle type, radio
connection, and preset controls
• Ability to dual assign steering
wheel control buttons
• Retains memory settings even
after battery disconnection or
interface removal (non volatile
memory)
• Provides illumination output
•
Retains the factory backup camera
• Micro-B USB updatable
Volkswagen
Beetle 2016-2019 ................................................
Golf Series 2015-Up ............................................
Jetta 2016-2019 ..................................................
Jetta GLI 2016-2018 ............................................
Passat...................................................2016-Up
Tiguan 2016-2017 ...............................................
• AXTC-VW2 interface
• AXTC-VW2 harness
• 3.5mm adapter
Product Info
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
2
CONNECTIONS
Front
Rear
Sub
AUX-IN
Rear View
SWC
3.5mm Adapter (for vehicles without Steering wheel
controls or aftermarket radios with a wire for SWC)
Boss (with SWC wire): Key 1 (Gray) - Brown
Kenwood / JVC (with SWC wire): Blue/Yellow - Brown
XITE: SWC-2 - Brown
Key-A or SWC-1 - Brown
Key-B or SWC-2 - Brown/White
* After programming, assign SWC buttons within radio menu
Universal
Radio*
{
3.5mm Adapter for Vehicles without Steering wheel controls
1) 3.5mm adapter Brown Brown/White From the , tie the and wires together
with tape or connector
2) 3.5mm adapter AXTC-VW2 HarnessConnect the to the 3.5mm jack from the
3) AXTC-VW2 Program the per the instructions on page 3. Disregard steps 4 & 5
Vehicle Connector
Aftermarket Radio
(radio’s features may vary)
Reset Button
LED Light
Yellow RCA - Rear View
Radio Connections
Black - Ground
Yellow - Battery power
Red - Accessory power
Orange - Illumination
Blue/White - Amp turn-on
Blue/Pink - VSS/Speed-Sense
Green/Purple - Reverse signal
Light Green - Parking brake
Gray - Front right speaker +
Gray/Black - Front right speaker -
White - Front left speaker +
White/Black - Front left speaker -
Green - Rear left speaker +
Green/Black - Rear left speaker -
Purple - Rear right speaker +
Purple/Black - Rear right speaker -
3
REV. 5/9/23 INSTAXTC-VW2
Open the driver’s door, and keep open during the programming process.
Cycle the ignition on.
Connect the to the , and then toAXTC-VW2 harness AXTC-VW2 interface
the wiring harness in the vehicle.
Locate the button on the steering wheel. Program the Volume Up
interface by tapping the button at a heartbeat pace until the Volume Up
LED light stops flashing.
*Only applicable if vehicle came with steering wheel controls
The LED light will flash & while the interface programs Green Red
the radio to the steering wheel controls. Once programmed, the
LED light will go out, then produce a pattern which will identify the
radio type installed. Refer to the section under Radio LED Feedback
Troubleshooting for radio types.
*Only applicable if vehicle came with steering wheel controls
The LED light will go out, then once again quickly flash & Green Red
while the interface programs itself to the vehicle. Once programmed,
the LED light will go out again, then turn solid .Green
Cycle the ignition off, then back on.
Test all functions of the installation for proper operation.
Note: Audio Mode must be selected in the MFI menu to allow track up
and down to function. Refer to the vehicle owner’s manual for more
information.
PROGRAMMING
1.
2.
3.
4.*
5.*
6.
7.
8.
Gr Deen & Red LE
Gr Deen LE
O
F
F
A
C
C
O
N
S
T
A
R
T
O
F
F
A
C
C
O
N
S
T
A
R
T
O
F
F
A
C
C
O
N
S
T
A
R
T
VOL
+
Tap Volume Up
Gr Deen & Red LE
Gr Deen or Red LE
