I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 11/16/23 INSTAXTC-MB3
ATTENTION: With the key out of the ignition, disconnect
the negative battery terminal before installing this
product. Ensure that all installation connections,
especially the air bag indicator lights, are plugged in
before reconnecting the battery or cycling the ignition to
test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
TABLE OF CONTENTS
Connections: LD-SWCX-MB3 2 .................................
Programming 3 .........................................................
Troubleshooting.....................................................4
Connector View 4 ......................................................
Mercedes SWC (Steering Wheel Control)
and Data Interface 2016-2021
INTERFACE FEATURES
• Designed for non-amplified models
• Provides accessory power (12 volt 10-amp)
• Provides wires for multimedia radios (park brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Designed to be compatible with all major radio brands
• Auto detects vehicle type, radio connection, and preset controls
• Ability to dual assign steering wheel control buttons
• Retains memory settings even after battery disconnection or
interface removal (nonvolatile memory)
• Provides illumination output
• Micro-B USB updatable
INTERFACE COMPONENTS
• AXTC-MB3 Interface
• LD-SWXC-MB3 Harness
• 3.5mm Adapter
APPLICATIONS
Mercedes
C Class 2016-2021 ..................................................................................
ML/GL 2016-2021 ...................................................................................
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors or
• Solder gun, solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
• Multimeter
Visit for more detailed information AxxessInterfaces.com
about the product and up-to-date vehicle specific applications.
Product Info
2 2
REV. 11/16/23 INSTAXTC-MB3
CONNECTIONS: LD-SWCX-MB3 HARNESS
LD-SWCX-MB3
Black - Ground wire
Yellow - Battery wire
Red - Accessory power
Green - Rear left speaker + output
Green/Black - Rear left - speaker output
Green/Purple - Reverse backup camera
Light Green - Parking brake
Orange - Illumination
Blue - Antenna turn on
Blue/White - Amp turn on
Blue/Pink - VSS/Speed-Sense
Gray - Front right + speaker
Gray/Black - Front right - speaker
White - Front left + speaker
White/Black - Front left - speaker
Purple - Rear right + speaker output
Purple/Black - Rear right - output
Front
Rear
Sub
AUX-IN
Rear View
SWC
Aftermarket Radio
(Your radio’s features may vary)
20-Pin
Vehicle Connector
Radio Connections
Interface
LED Light
Reset Button
3.5mm Adapter (for vehicles with Steering wheel controls
or aftermarket radios with a wire for SWC)
Boss (with SWC wire): Key 1 (Gray) - Brown
Kenwood / JVC (with SWC wire): Blue/Yellow - Brown
XITE: SWC-2 - Brown
Key-A or SWC-1 - Brown
Key-B or SWC-2 - Brown/White
* After programming, assign SWC buttons within radio menu
Universal
Radio*
{
3.5mm Adapter for Vehicles without Steering wheel controls
1) 3.5mm adapter Brown Brown/White From the , tie the and wires together
with tape or connector
2) 3.5mm adapter AXTC-MB3 HarnessConnect the to the 3.5mm jack from the
3) AXTC-MB3 Program the per the instructions on page 3. Disregard steps 4 & 5
3
REV. 11/16/23 INSTAXTC-MB3
Open the driver’s door, and keep open during the programming process.
Cycle the ignition on.
Connect the to the .AXTC-MB3 harness AXTC-MB3 interface
Locate the button on the the steering wheel. Program the Volume Up
interface by tapping the button until the LED stops flashing.Volume Up
The LED light will flash & while the interface programs the Green Red
radio to the steering wheel controls. Once programmed, the LED light
will go out, then produce a pattern which will identify the radio type
installed.
The LED light will go out, then once again quickly flash & Green Red
while the interface programs itself to the vehicle. Once programmed,
the LED light will go out again, then turn solid .Green
Cycle the ignition off, then back on.
Test all functions of the installation for proper operation.
PROGRAMMING
1.
2.
3.
4.
5.
6.
7.
8.
Gr Deen & Red LE
Gr Deen or Red LE
Gr Deen & Red LE
Gr Deen LE
O
F
F
A
C
C
O
N
S
T
A
R
T
O
F
F
A
C
C
O
N
S
T
A
R
T
O
F
F
A
C
C
O
N
S
T
A
R
T
VOL
+
Tap Volume Up
