AXSSO-FD2
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 12/1/21 INSTAXSSO-FD2
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
NOTE: Refer to the instructions included with
the aftermarket radio.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Zip ties • Cutters (for zip ties)
• USB Micro-B cable
(Axxess part number AXUSB-MCBL)
TABLE OF CONTENTS
Programming .........................................................2
Connections ............................................................3
Operation ................................................................4
Ford Stop/Start Override Interface 2019-Up
APPLICATIONS
Allows the override of the STOP/START engine feature
The factory STOP/START button can resume the STOP/START feature
Can be used with either a factory or aftermarket radio
Vehicle type configured through the Axxess Updater software program
Simple plug n’ play installation, no wiring required
The is designed to disengage the STOP/START feature of the vehicle and keep that feature disengaged, even after the key has been AXSSO-FD2
cycled. The AXSSO-FD2 will work with either an aftermarket radio or a factory radio. A simple plug n’ play installation is all that is required to install
the device in the vehicle. Programming will be enabled through a Windows 10 computer via the Axxess Updater software program.
Ford
Bronco Sport 2021
Escape 2020-2021
Explorer 2020-2021
Ranger 2019-2021
Transit 2020-2021
Transit Connect 2019-2021
• AXSSO-FD2 interface
• AXSSO-FD2 harness
Product Info
INTRODUCTION
2
PROGRAMMING
(Figure A) (Figure B) (Figure C)
1.
2.
3.
4.
Download and install the Axxess Updater software program from:
axxessinterfaces.com/resources/updater-software
On the next screen that opens, select the year, make, and model of the
vehicle, then press Program Interface. (Figure B)
Connect the micro-B USB cable (sold separately) to the computer and
AXSSO-FD2 interface. Open the software program and Axxess Updater
wait until the word is shown in the bottom left of the screen. Ready
Select . (Figure A)Stop / Start
When the Configuration Successful box pops up, the programming
process is complete. (Figure C)
Continue to Installation
3
REV. 12/1/21 INSTAXSSO-FD2
To OBD2
Harness
To
Vehicle
INSTALLATION
These vehicles will connect at the OBD2 connector, located under the driver’s side dashboard:
(Figure A)
(Figure B)
Ford
Bronco Sport ..................2021
Escape ............................2020-2021
Explorer .........................2020-2021
Ranger ...........................2019-2021
Transit ............................2020-2021
Transit Connect ..............2019-2021
From the OBD2 connector in the dash:
1. Disconnect the factory OBD2 connector from under the dash. (Figure A)
2. Plug the AXSSO-FD2 harness into the OBD2 connector.
3. Connect the AXSSO-FD2 to the wiring harness harness in the dash.
4. Plug the AXSSO-FD2 harness into the AXSSO-FD2 interface.
5. Zip tie the harness securely under the dash to avoid it from sagging. (Figure B
