Seite 1/2
AXRSEH-GL29
INSTALLATIO N INSTRUCTI O N S
REV. 4/20/20
Š COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
• Retains the A/V-IN jack (if applicable)
• Provides A/V output to the factory installed rear seat overhead
entertainment system *
• Designed for models that have a DVD player built into the factory radio
INTERFACE FEATURES
• Wire cutter • Crimping tool
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
GM RSE A/V Harness 2007-Up
APPLICATIONS
• AXRSEH-GL29 harness
• Connect to the AXRSEH-GL29 harness to the wiring harness in the
vehicle located at the radio location.
INTERFACE COMPONENTS
CONNECTIONS TO BE MADE
INSTALLATION
BUICK
Enclave 2008-Up
Cadillac
Escalade 2007-2011
Escalade ESV 2007-2011
Escalade EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche 2007-2013∆
Equinox 2007-2009
Silverado 2500/3500 2014∆
Silverado (new body) 2007-2013∆
Suburban 2007-2014∆
Tahoe 2007-2014∆
Traverse 2009-Up
GMC
Acadia 2007-2016
Acadia Limited 2017
Sierra 2500/3500 2014∆
Sierra (new body) 2007-2013∆
Yukon/Yukon XL 2007-2014∆
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
* Only applicable for models with a second row RSE
∆ For 2012-Up models with NAV use the AXRSEH-G2.
•
Connect the wire with a ring terminal to the chassis of the aftermarket radioBlack
.
• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the
aftermarket radio:
• Connect the Yellow RCA jack to the video in.
• Connect the and RCA jacks to the audio in.Red White
• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the
aftermarket radio:
• Connect the Yellow RCA jack to the video out.
• Connect the and RCA jacks to the audio out.Red White
AXRSEH-GL29
REV. 4/20/20
Š COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INSTRUCCIONES DE INSTALACIÓN
• Retiene el conector A/V-IN (si aplica)
• Proporciona salida A/V al sistema de entretenimiento instalado en el
asiento trasero de fĂĄbrica *
• Diseñado para los modelos que tienen un reproductor de DVD
integrado en la radio de fĂĄbrica
CARACTERÍSTICAS DE LA INTERFAZ
• Cortacables • Ponchadora
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
HERRAMIENTAS REQUERIDAS
GM ArnĂŠs A/V RSE 2007 y Mas
APLICACIONES
• Arnés AXRSEH-GL29
• Conectar al arnés AXRSEH-GL29 al arnés de cables del vehículo
situado en la ubicaciĂłn de la radio.
COMPONENTES DE LA INTERFAZ
CONEXIONES
INSTALACIÓN
BUICK
Enclave 2008-Up
Cadillac
Escalade 2007-2011
Escalade ESV 2007-2011
Escalade EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche 2007-2013∆
Equinox 2007-2009
Silverado 2500/3500 2014∆
Silverado (nueva carrocería) 2007-2013∆
Suburban 2007-2014∆
Tahoe 2007-2014∆
Traverse 2009-Up
GMC
Acadia 2007-2016
Acadia Limited 2017
Sierra 2500/3500 2014∆
Sierra (nueva carrocería) 2007-2013∆
Yukon/Yukon XL 2007-2014∆
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
* Sólo aplicable a modelos con una segunda la RSE
∆ Para los modelos 2012 y mas con NAV utilice el AXRSEH-G2.
•
Conecte el cable negro con una terminal de aro al chasĂ­s del radio de mercado secundario
.
• Desde los conectores RCA etiquetados “DE LA ENTRADA TRASERA A/V” a la entrada
A/V de la radio de mercado secundario:
• Conecte el conector RCA al entrada de video.amarillo
• Conecte el conectores RCA y rojo blanco al entrada de audio.
• Desde los conectores RCA etiquetados “A LA PANTALLA DE TECHO” a la salida A/V
de la radio de mercado secundario:
• Conecte el conector RCA al salida de video.amarillo
• Conecte el conectores RCA y rojo blanco al salida de audio.
