Seite 1/2
AXRSEH-G2
INSTALL ATION INSTRUCTI O NS
REV. 4/20/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
• Retains the A/V-IN jack (if applicable)
• Provides A/V output to the factory installed rear seat overhead
entertainment system *
Designed for models that have a DVD player built into the factory radio
INTERFACE FEATURES
• Wire cutter • Crimping tool
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
GM
(with NAV)
RSE A/V Harness 2012-2014
APPLICATIONS
• AXRSEH-G2 harness
Connect to the AXRSEH-G2 harness to the wiring harness in the
vehicle located at the radio location.
INTERFACE COMPONENTS
CONNECTIONS TO BE MADE
INSTALLATION
* Only applicable for models with a second row RSE
Connect the wire with a ring terminal to the chassis of the aftermarket radioBlack
.
From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the
aftermarket radio:
• Connect the Yellow RCA jack to the video in.
• Connect the and RCA jacks to the audio in.Red White
From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the
aftermarket radio:
• Connect the Yellow RCA jack to the video out.
• Connect the and RCA jacks to the audio out.Red White
CADILLAC
Escalade 2012-2014
CHEVROLET
Avalanche 2012-2013
Silverado 2500/3500 2014
Silverado 2012-2013
CHEVROLET (CONT)
Suburban 2012-2014
Tahoe 2012-2014
GMC
Sierra 2500/3500 2014
Sierra 2012-2013
Yukon 2012-2014
AXRSEH-G2
REV. 4/20/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INSTRUCCIONES DE INSTAL ACN
• Retiene el conector A/V-IN (si aplica)
• Proporciona salida A/V al sistema de entretenimiento instalado en el
asiento trasero de fábrica *
• Diseñado para los modelos que tienen un reproductor de DVD
integrado en la radio de fábrica
INTERFACE FEATURES
• Cortacables • Ponchadora
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
HERRAMIENTAS REQUERIDAS
GM
(con NAV)
Arnés A/V RSE 2012-2014
APLICACIONES
• Arnés AXRSEH-G2
COMPONENTES DE LA INTERFAZ
CONEXIONES
* Sólo aplicable a modelos con una segunda fila RSE
CADILLAC
Escalade 2012-2014
CHEVROLET
Avalanche 2012-2013
Silverado 2500/3500 2014
Silverado 2012-2013
CHEVROLET (CONT)
Suburban 2012-2014
Tahoe 2012-2014
GMC
Sierra 2500/3500 2014
Sierra 2012-2013
Yukon 2012-2014
Conectar al arnés AXRSEH-G2 al arnés de cables del vehículo situado
en la ubicación de la radio.
INSTALACIÓN
Conecte el cable negro con una terminal de aro al chasís del radio de mercado secundario
.
Desde los conectores RCA etiquetados “DE LA ENTRADA TRASERA A/V” a la entrada
A/V de la radio de mercado secundario:
• Conecte el conector RCA al entrada de video.amarillo
• Conecte el conectores RCA y al entrada de audio.rojo blanco
Desde los conectores RCA etiquetados “A LA PANTALLA DE TECHO” a la salida A/V
de la radio de mercado secundario:
• Conecte el conector RCA al salida de video.amarillo
• Conecte el conectores RCA y al salida de audio.rojo blanco
