AXRC-GMLN3
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com Š COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 5/10/22 INSTAXRC-GMLN3
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Cutting tool
• Tape
• Crimping tool and connectors,
(example: butt-connectors, bell caps, etc.)
or
• Solder gun, solder, and heat shrink
TABLE OF CONTENTS
Connections ............................................................2
Installation ............................................................. 3
Testing ....................................................................3
Data Interface for GM Select Models 2005-2012
APPLICATIONS
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory
Power) if equipped
• Retains all warning chimes
• Used in non-amplified systems or
when removing amplied system
• Small in size
• USB updatable
Chevrolet
Cobalt 2007-2010
HHR 2006-2011
Malibu 2008-2012
Pontiac
G5 2005-2010
G6 (5th digit VIN J, K, or L) 2009
G6 2010
Solstice 2006-2009
Saturn
Aura 2007-2009
Sky 2007-2009
• AXRC-GMLN3 interface
• AXRC-GMLN3 harness
Visit AxxessInterfaces.com for up-to-date vehicle specic applications
2
CONNECTIONS
From the AXRC-GMLN3 harness to the aftermarket radio, connect as indicated:
• wire to the ground wire.Black
• Yellow wire to the constant/memory wire.
• wire to the accessory wire.Red
• wire to the antenna turn on wire.Blue
• Orange/White wire to the illumination wire.
Note: If the aftermarket radio has no illumination wire, tape off the Orange/White wire.
• White wire to the left front (+) speaker wire.
• White/Black wire to the left front (-) speaker wire.
• wire to the right front (+) speaker wire.Gray
• Gray/Black wire to the right front (-) speaker wire.
• Green wire to the left rear (+) speaker wire.
• Green/Black wire to the left rear (-) speaker wire.
• wire to the right rear (+) speaker wire.Purple
• wire to the right rear (-) speaker wire.Purple/Black
The following (3) wires are only for multimedia/navigation radios that require these wires.
• wire to the VSS/speed sense wire.Blue/Pink
• Green/Purple wire to the reverse wire.
• Light Green wire to the parking brake wire.
3
REV. 5/10/22 INSTAXRC-GMLN3
1. With all connections completed reconnect the negative battery terminal.
2. Plug the AXRC-GMLN3 harness AXRC-GMLN3 into the interface and then to the wiring
harness in the vehicle.
Attention! If the interface loses power for any reason, the following steps will need to be
performed again.
1. To initialize the interface, turn the ignition on and wait for (30) seconds.
2. Cycle the ignition off, then back on.
3. Test all functions of the aftermarket radio installation fo r proper operation, including proper
balance and fader operation.
4.
Close all the doors then turn the key off. The radio should stay on until the driver’s door
is re-opened.
Note: If the radio doesn’t come on within (60) seconds, turn the key to the off position,
disconnect the interface, check all connections, reconnect the interface, and then try again.
INSTALLATION
TESTING
