Installation instructions for part AXRC-GM5
REV. 1/21/2020 INSTAXRC-GM5
axxessinterfaces.com • metraonline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
Connections to be made ............................................2
Installing the AXRC-GM5 ...........................................3
Initializing the AXRC-GM5 .........................................3
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse,
and speed sense)
• Used in both amplified and non-amplified sound
systems
• Used in models without OnStar
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Micro “B” USB updatable
INTERFACE FEATURES
• Wire cutter • Crimp tool • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
AXRC-GM5
GM Data Bus Interface
2005-2006
APPLICATIONS
• AXRC-GM5 interface • AXRC-GM5 harness
INTERFACE COMPONENTS
Table of Contents
CHEVROLET
Equinox 2005-2006
OLDSMOBILE
Torrent 2006
AXRC-GM5
Connections to be made
From the AXRC-GM5 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
• Connect the wire to the amp turn-on wire.Blue/White
• If the aftermarket radio has an illumination wire, connect the Orange
wire to it.
• Connect the wire to the right front positive speaker output.Gray
• Connect the wire to the right front negative speaker output.Gray/Black
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative speaker output.Purple/Black
The following (3) wires are only for multimedia/navigation radios that
require these wires.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
AXRC-GM5
With the key in the off position:
• Connect the AXRC-GM5 harness into the interface.
• Connect the AXRC-GM5 harness to the vehicle.
Attention: If the interface loses power for any reason, the following steps
will need to be performed again.
• Turn the key (or push-to-start button) to the ignition position and wait
until the radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key
to the off position, disconnect the interface, check all connections,
reconnect the interface, and then try again.
• Turn the key to the off position, and then to the accessory position.
Test all functions of the installation for proper operation, before
reassembling the dash.
Installing the AXRC-GM5 Initializing the AXRC-GM5
