Seite 1/8
Installation instructions for part AXRC-GM44
REV. 5/6/2020 INSTAXRC-GM44
axxessinterfaces.com • metraonline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• Provides accessory power
(12-volt 10-amp)
• Retains R.A.P. (retained
accessory power)
•
Provides NAV outputs (parking
brake, reverse, and speed sense)
• Used in non-amplified
models, or when bypassing a
factory amplifier
•
Used in models without OnStar
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Micro “B” USB updatable
INTERFACE FEATURES
• Wire cutter • Crimping tool • Tape • Solder gun
• Connectors (butt-connectors, bell caps, etc.)
TOOLS REQUIRED
APPLICATIONS
• AXRC-GM44 interface
• AXRC-GM44 harness
INTERFACE COMPONENTS
*Only for models with factory navigation.
Note: This interface will not retain OnStar.
CHEVROLET
Avalanche* 2012-2013
Express* 2013-2015
Malibu (with single color,
monochrome screen)
2013-2015
Malibu Limited (with single
color, monochrome screen)
2016
CHEVROLET (CONT)
Silverado* 2012-2013
Silverado 2500/3500* 2014
Suburban* 2012-2014
Tahoe* 2012-2014
Trax 2015-2016
GMC
Savana* 2013-2015
Sierra * 2012-2013
Sierra 2500/3500* 2014
Yukon / Yukon XL* 2012-2014
Connections to be made ........................................ 2
Installing the AXRC-GM44 3 .....................................
Initializing the AXRC-GM44 3 ...................................
Table of Contents
AXRC-GM44
From the AXRC-GM44 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
• Tape off and disregard the wire, it will not be used in this application.Pink
• Connect the wire to the power antenna wire.Blue/White
• If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
• Connect the wire to the right front positive speaker output.Gray
• Connect the wire to the right front negative speaker output.Gray/Black
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative speaker output.Purple/Black
The following (3) wires are only for multimedia/navigation radios that require these
wires.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
Connections to be made
AXRC-GM44
Installing the AXRC-GM44
With the key in the off position:
• Connect the AXRC-GM44 harness into the interface, and then to the wiring
harness in the vehicle.
Initializing the AXRC-GM44
Attention: If the Axxess interface loses power for any reason, the following
steps will need to be performed again.
• Turn the key (or push-to-start button) to the ignition position and wait until the
radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
• Turn the key to the off position, and then to the accessory position.
• Test all functions of the installation for proper operation, before reassembling the
dash.
