Installation instructions for part AXRC-GM3
REV. 2/4/2020 INSTAXRC-GM3
axxessinterfaces.com • metraonline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and speed sense)
• Used in non-amplified models, or when bypassing a factory amplifier
• Used in models without OnStar
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Micro “B” USB updatable
INTERFACE FEATURES
• Cutting tool • Crimping tool • Tape • Connectors
(example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
AXRC-GM3
Cadillac Data Interface
1996-2005
APPLICATIONS
• AXRC-GM3 interface • 32-pin Cadillac harness
INTERFACE COMPONENTS
CADILLAC
Catera 1997-2001
Deville 1996-1999
Deville* 2000-2005
Eldorado 1996-2002
Seville 1996-1997
Seville* 1998-2004
*Note: You must bypass the factory amp in
these vehicles to use this interface.
Connections to be made ........................................ 2
Installing the Axxess Interface 3 .............................
Initializing the Axxess Interface 3 ...........................
Table of Contents
AXRC-GM3
From the AXRC-GM3 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
• Connect the wire to the power antenna wire.Blue
• If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
• Connect the wire to the right front positive speaker output.Gray
• Connect the wire to the right front negative speaker output.Gray/Black
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative speaker output.Purple/Black
The following (3) wires are only for multimedia/navigation radios that require these
wires.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
Connections to be made
AXRC-GM3
Installing the Axxess Interface
With the key in the off position:
• Connect the AXRC-GM3 harness into the interface, and then to the wiring harness
in the vehicle.
Initializing the Axxess Interface
Attention: If the Axxess interface loses power for any reason, the following
steps will need to be performed again.
• Turn the key (or push-to-start button) to the ignition position and wait until the
radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
• Turn the key to the off position, and then to the accessory position.
• Test all functions of the installation for proper operation, before reassembling the
dash.
