AXLOCM-80
INSTALL ATION INSTR UCTIONS
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The LOC is designed to convert (2) channels of speaker level audio into (2) channels of line
level audio that can be used by OEM amplifiers. It can also be used with OEM radios to add
aftermarket amplifiers. This device will also detect the presence of an audio signal and then
generate a +12V output that can be used to turn-on an aftermarket amplifier.
Features and specifications
The LOC is able to handle 40 watts per channel continuous input without overheating. The
input circuitry is designed to correct the crossover distortion commonly found on standard
LOC's, while providing a high to low level step down of 6:1. Output audio level is adjustable
using the onboard, high quality potentiometers. The remote output or amplifier trigger
is rated at 500mA (+12V) and will easily handle an outboard relay if additional current is
needed. The remote output will trigger instantaneously when the LOC detects a DC voltage
on the white, left + audio input wire above 5V or a very low audio signal. It will shut off 60
seconds after no signal is detected.
Installation
The LOC should be installed on a stereo’s speaker output wires, or the output wires on an
OEM amplifier of up to 40 watts per channel. These wires can be found behind the stereo in
the dash, on the output of an OEM amplifier, or on the input terminals on the OEM speakers.
Please refer to the wiring diagram for the input connection details.
(Continued on other side)
2 Channel Adjustable, Line Output Converter (LOC)
with Built-in Amplifier Remote Generator
AXLOCM-80
INSTALL ATION INSTR UCTIONS
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
Wire color and function
The audio and power input wire colors are an EIA standard for car stereo applications as follows:
The following (2) wires can be connected directly to the amplifier being installed for simplicity
:
Yellow = battery +12v input
Black = ground input
Blue = remote +12v output
White = left front (+) input
White/Black = left front (-) input
Gray = right front (+) input
Gray/Black = right front (-) input
Black/White = reference ground (-) (optional if noise is present)
Note: Be sure that all audio input connections are in phase (polarized) with each other. Failure to
do this will result in poor bass response and low quality audio.
Adjusting the LOC for maximum performance: After completing all of the necessary connections,
turn the LOC adjustment pots all of the way down by rotating them completely counter-clockwise.
Next, turn the stereo system on and adjust the main volume control on the stereo to approximately
3/4 maximum volume. Select one of the adjustment pots on the LOC and turn it slowly clockwise
until you notice audio distortion and then stop. Turn the remaining pots to the same position as the
previously adjusted pot. The audio set-up of the LOC is now complete and ready to be enjoyed.
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
K PNOWLEDGE IS OWER
Enhance your ins tallat ion a nd fabrica tion skills by
enrolling in the most re cognized a nd spect ed re
mobile elec t nics school in our indus try.ro
Log ont o www.insta llerinst itut e.com or call
800-354-6 782 for mo informa tion a nd take s teps re
tow ard a bet ter tom orrow.
®
Metra recommends MECP
certified technicians
