AXLOC4-80A
INSTALL ATION INSTR UCTIONS
REV. 12/18/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
Wire Color & Function: The audio and power input wire colors are an EIA standard for
car stereo applications as follows.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC4-80A. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Adjusting the AXLOC4-80A for maximum performance:
After completing all of the necessary connections, turn the AXLOC4-80A adjustment pots all of
the way down by rotating them completely counter-clockwise. Now, turn the stereo system on
and adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select
one of the adjustment pots on the AXLOC4-80A and turn it slowly clockwise until you notice audio
distortion and then stop. Turn the remaining pot to the same position as the previously adjusted
pot. The audio set-up of the AXLOC4-80A is now complete and ready to be enjoyed.
INPUT HARNESS
White =
LEFT Front (+) Input
White/Black =
LEFT Front (-) Input
Gray =
RIGHT Front (+) Input
Gray/Black =
RIGHT Front (-) Input
Green =
LEFT Rear (+) Input
Green/Black =
LEFT Rear (-) Input
Purple =
RIGHT Rear (+) Input
Purple/Black =
RIGHT Rear (-) Input
Black = Reference Ground (-)
(Reference ground optional if noise is present)
AXLOC4-80A
INSTALL ATION INSTR UCTIONS
REV. 12/18/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
4 Channel, Adjustable Line-Output Converter
The AXLOC4-80A is designed to convert 4 channels of speaker level audio to
line level audio. This allows for the installation of line level products such as
amplifiers, EQs and crossovers on radio’s that do not have RCA line level outputs.
Features:
80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly
Found On Other Brands of LOCs, 6:1 Step Down with Variable Output, Detachable
Input Plug, Gold Flashed RCAs, Attractive & Durable Enclosure.
