AXLOC-RGC AXLOC-RGC
INSTALLATION INSTRUCTIONS
REV. 4/24/24 REV. 4/24/24
© COPYRIGHT 2024 METRA ELECTRONICS CORPORATION © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION
Integrate AxxessInterfaces.com Integrate AxxessInterfaces.com
Wire Color & Function: The audio input wire colors are an EIA standard for car stereo
applications as follows.
INPUT HARNESS
White = Left front (+) input
White/Black = Left front (-) input
Gray = Right front (+) input
Gray/Black = Right front (-) input
Brown (x2) = Reference ground (-)
(Reference ground optional if noise is present)
The is designed to convert speaker level audio to line level audio. This allows for AXLOC-RGC
the installation of line level products such as amplifiers, EQs and crossovers on systems that
do not have RCA line level outputs.
Adjusting the AXLOC-RGC for maximum performance: After completing all of the necessary
connections, turn the AXLOC-RGC adjustment pot all of the way down by rotating it
completely counter-clockwise. Now, turn the stereo system on and adjust the main volume
control on the stereo to approximately 3/4 maximum volume. Locate the adjustment pot on
the AXLOC-RGC and turn it slowly clockwise until you notice audio distortion and then stop
The audio set-upof the AXLOC-RGC is now complete and ready to be enjoyed.
Note: If using external Bass knob, make sure your “Output Level Adjustment” knob is
turned all the way down (turned all the way to the left)
Features: 55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly Found On
Other Brands of LOCs, 6:1 Step Down with Fixed Output, Gold Plated RCAs, Attractive & Durable Enclosure
2 Channel, Adjustable Line Output Converter
Note:
Be sure that all audio input connections
are polarized or in phase with each other.
That is, the positive output wires from the
audio source need to be connected to the
corresponding positive input wires of the
AXLOC-RGC. The same goes for the negative
audio wires. Failure to do this will result in
poor bass response and low quality audio.
INSTRUCCIONES DE INSTALACIÓN
El está diseñado para convertir el nivel de audio de las bocinas a un audio a nivel de AXLOC-RGC
nea. Esto permite la instalación de productos a nivel de línea como amplificadores, ecualizadores
y divisores de frecuencia en los sistemas que no cuentan con salidas RCA a nivel de línea.
Ajuste del AXLOC-RGC para obtener el máximo rendimiento: Después de completar todas las
conexiones necesarias, gire el AXLOC- RGC macetas hasta el fondo girándolas completamente en
sentido antihorario. Ahora, encienda el sistema estéreo y ajuste el control de volumen principal en
el estéreo a aproximadamente 3/4 de volumen máximo. Seleccione uno de las ollas de ajuste en
el AXLOC-RGC y gírelo lentamente en el sentido de las agujas del reloj hasta que note distorsión
de audio y luego detenga la configuración de audio del AXLOC-RGC p1-ya está completo y listo para
ser disfrutado.
Nota: Si usa la perilla de graves externa, asegúrese de que la perilla de "Ajuste del nivel de salida"
esté girada completamente hacia abajo (girada completamente hacia la izquierda)
Características: El voltaje máximo de entrada es de 55 watts. El circuito de entrada corrige la distorsión
de cruce por cero comúnmente encontrada en otras marcas de convertidores de salida de línea.
Reducción de voltaje 6:1 con salida fixed. Cables RCA recubiertos en oro. Empaque atractivo y duradero.
Función y color del cableado: Los colores del cable de entrada de audio son un estándar de la EIA
para las aplicaciones para estéreos de auto, como se detalla a continuación
.
.
MAZO DE CABLES DE ENTRADA
Blanco = Entrada izquierda delantera (+)
Blanco/Negro = Entrada izquierda delantera (-)
Gris = Entrada derecha delantera (+)
Gris/Negro = Entrada derecha delantera (-)
Marrón (x2) = Puesta a Tierra (-)
(Puesta a tierra opcional si hay ruido)
Convertidor de salida de línea ajustable de dos canales
Nota:
Asegúrese de que todas las conexiones de en-
trada de audio estén polarizadas o en fase, es decir, los
cables positivos de salida de la fuente de audio deben
estar conectados a los cables positivos de entrada del
AXLOC-RGC. La misma configuración aplica para los
cables negativos de audio. Si los cables no se conectan
de esta manera, el resultado será una reproducción de
bajos deficiente y un audio de baja calidad.
