AXLOC-GMLN1
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 12/6/22 INSTAXLOC-GMLN1
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the
ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip-ties
TABLE OF CONTENTS
Applications.............................................................1
Installation ............................................................. 2
Diagram .................................................................. 3
GM LOC (Line Output Converter) AXLOC-GMLN1
(for Non-Amplified Vehicles) 2006-2021
APPLICATIONS
Buick
Lucerne 2006-2011
Cadillac
DTS 2006-2011
Escalade 2007-2014
SRX 2007-2009
Chevrolet
Avalanche 2007-2013
Captiva Sport 2012-2015
Cheyenne (RPO IOB) 2016-2018
Chevrolet (cont.)
Cheyenne 2012-2014
Equinox 2007-2009
Express van (Full Size) 2008-2021
Impala Limited (Fleet) 2014
Impala 2006-2013
Monte Carlo 2006-2007
Silverado Pickup 2007-2013
Spark (RPO IOB) 2016-2018
Suburban 2007-2014
Chevrolet (cont.)
Tahoe 2007-2014
Traverse 2009-2017
GMC
Acadia 2007-2016
Savanna Full Size Van 2008-2014
Sierra (New Body) 2007-2013
Sierra 2500/3500 2014
Yukon XL / Denali 2007-2014
Yukon 2007-2014
Hummer
H2 2008-2009
Pontiac
Torrent 2007-2009
Saturn
Outlook 2007-2009
VUE 2008-2009
Suzuki
XL-7 2007-2009
KIT COMPONENTS
• AXLOC-GMLN1 Wiring Harness
• Gain Controller
• 12v-500mA Remote Wire
• Auxiliary Cable
For dash disassembly instructions, refer to metraonline.com. Enter the year, make, and model of the vehicle in the Vehicle Fit Guide Radio Install Kits for .
• Designed to provide (2) channels of low-level audio output from the factory system.
• Allows for the installation of an amplifier for speakers or subwoofers.
• Gain Controller included to adjust the overall output.
• 12v-500mA remote wire activated with signal sense.
• 55-watts per channel
• Designed for non-amplified vehicles.
Note: A single pole double throw (SPDT) relay is recommended when installing multiple amplifiers.
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date vehicle specific applications.
2
INSTALLATION
1.
Disconnect the harness from the factory
tuner and install the AXLOC-GMLN1
harness provided with this kit.
2. Mount the gain controller in a suitable
location, and connect the auxiliary cable
to the , then to the Gain BASS KNOB
Connector of the AXLOC harness.
3.
Install the aftermarket amplifier and
run an RCA pair (sold separately) to
the line converter.
4. Connect the remote wire, plug in the
device and secure all connections prior
to testing.
NOTE: If the vehicle is equipped with active
noise cancellation microphones (ANC), it is
recommended that they are disabled to prevent
potential noise when installing subwoofers.
3
REV. 12/6/22 INSTAXLOC-GMLN1
DIAGRAM
TO RADIO
TO VEHICLE
Remote
Gain Cont.
Line Out Convertor Bass Knob (Top View)
Aux. Cable
Bass Knob (Front View)
LD-AXLOC-GMLN1
Output Level Adjustment
NOTE: If using external Bass knob, make sure
y el Adjustment” knob is turned our “Output Lev
all the way down (turned all the way to the left)
Line Out Convertor
(Front View)
