AXLOC-GC
INSTALL ATION INSTR UCTIONS
REV. 4/29/21
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
Wire Color & Function: The audio input wire colors are an EIA standard for car stereo
applications as follows.
INPUT HARNESS
= Left front (+) inputWhite
= Left front (-) inputWhite/Black
= Right front (+) inputGray
Gray/Black = Right front (-) input
Brown (x2) = Reference ground (-)
(Reference ground optional if noise is present)
Note:
Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC-GC. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
The AXLOC-GC is designed to convert speaker level audio to line level audio. This allows for the
installation of line level products such as amplifiers, EQs and crossovers on systems that do not
have RCA line level outputs.
Features:
55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Fixed Output, Gold Plated RCAs, Attractive & Durable Enclosure
2 Channel, Adjustable Line Output Converter
AXLOC-GC
REV. 4/29/21
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INSTRUCCIONES DE INSTALACIÓN
Función y color del cableado: Los colores del cable de entrada de audio son un estándar de
la EIA para las aplicaciones para estéreos de auto, como se detalla a continuación
.
MAZO DE CABLES DE ENTRADA
= Entrada izquierda delantera (+)Blanco
= Entrada izquierda delantera (-)Blanco/Negro
= Entrada derecha delantera (+)Gris
= Entrada derecha delantera (-)Gris/Negro
= Puesta a Tierra (-) Marrón (x2)
(Puesta a tierra opcional si hay ruido)
Nota:
Asegúrese de que todas las conexiones de entrada de audio estén polarizadas o en
fase, es decir, los cables positivos de salida de la fuente de audio deben estar conectados
a los cables positivos de entrada del AXLOC-GC. La misma configuración aplica para los
cables negativos de audio. Si los cables no se conectan de esta manera, el resultado será
una reproducción de bajos deficiente y un audio de baja calidad
.
El AXLOC-GC está diseñado para convertir el nivel de audio de las bocinas a un audio a nivel de
línea. Esto permite la instalación de productos a nivel de línea como amplificadores, ecualizadores y
divisores de frecuencia en los sistemas que no cuentan con salidas RCA a nivel de línea.
Características:
El voltaje máximo de entrada es de 55 watts. El circuito de entrada corrige la distorsión
de cruce por cero comúnmente encontrada en otras marcas de convertidores de salida
de línea. Reducción de voltaje 6:1 con salida fixed. Cables RCA recubiertos en oro.
Empaque atractivo y duradero.
Convertidor de salida de línea ajustable de dos canales
