AXi-TL24-R INSTALLATION MANUAL
Tech Support: 844-AXX-ESSI WWW.AXXESSINTERFACES.COM
AXi-RGB3 AXi-RGB2
PLUG & PLAY WIRING HARNESS COMPATIBLE WITH
Rev. 4.0 081915
PLEASE REVIEW THIS INSTALLATION MANUAL
CAREFULLY BEFORE BEGINNING ANY WORK
2
Table Of Contents
………………………………….……….
IMPORTANT
IMPORTANT
IMPORTANT
IMPORTANT IMPORTANT WARNING
WARNING
WARNING
WARNINGWARNING
This product includes instructions for installation which must be carefully
followed. The instructions are worded in such a manner to assume that the
installer is capable of completing these type of electronic installations. If you
are unclear as to what you are instructed to do or believe that you do not
understand the instructions so as to properly and safely complete the
installation you should consult a technician who does have this knowledge and
understanding.
Failure to follow these instructions carefully and to install the interface as
described could cause harm to the vehicle or to safety systems on the vehicle.
Interference with certain safety systems could cause harm to persons as well.
If you have any questions in this regard please call the Metra Help line at
1-844-299-3774 and for ordering questions call Metra at 1-800-221-0932.
COMPATIBLE VEHICLES/WIRING LOCATIONS…....3
PRECAUTIONS.…………………………………….....……...4
WIRING CONNECTIONS……………………….…...….....5
PLUG & PLAY HARNESS INSTALLATION……...........6
TESTING OPERATION………………………….……...…..7
VEHICLE REASSEMBLY CHECKLIST…………...…......8
3
.
COMPATIBLE VEHICLES
MAKE MODEL OPTIONS YEAR
TOYOTA 4RUNNER -2013 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2012
TOYOTA AVALON -2014 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2013
TOYOTA CAMRY -2014 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2012
TOYOTA COROLLA -2013 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2012
TOYOTA HIGHLANDER MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2013
TOYOTA PRIUS -2015 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2012
TOYOTA RAV4 -2015 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2012
TOYOTA TACOMA -2013 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2012
TOYOTA VENZA -2014 MUST HAVE FACTORY NAVIGATION. NON JBL NAVIGATION 2013
ACCESSORY GROUND REVERSE WIRE LOCATION
MAKE MODEL YEAR ACCESSORY GROUND REVERSE
TOYOTA 4RUNNER 2012-2013 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA AVALON 2013-2014 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA CAMRY 2012-2014 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA COROLLA 2012-2013 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA HIGHLANDER 2013 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA PRIUS 2012-2015 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA RAV4 2012-2015 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA TACOMA 2012-2013 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
TOYOTA VENZA 2013-2014 RED WIRE @ AXi-TL24-R BLACK WIRE @ AXi-TL24-R REVERSE TAIL LAMP
Accessory and Ground wires are open end wires found on the AXi-TL24-R harness.
