AXi-NI24-R INSTALLATION MANUAL
Tech Support: 844-AXX-ESSI WWW.AXXESSINTERFACES.COM
AXi-RGB1 AXi-RGB2 AXi-RGB3
PLUG & PLAY WIRING HARNESS COMPATIBLE WITH
Rev. 4.0 081915
PLEASE REVIEW THIS INSTALLATION MANUAL
CAREFULLY BEFORE BEGINNING ANY WORK
2
Table Of Contents
………………………………….……….
IMPORTANT
IMPORTANT
IMPORTANT
IMPORTANT IMPORTANT WARNING
WARNING
WARNING
WARNINGWARNING
This product includes instructions for installation which must be carefully
followed. The instructions are worded in such a manner to assume that the
installer is capable of completing these type of electronic installations. If you
are unclear as to what you are instructed to do or believe that you do not
understand the instructions so as to properly and safely complete the
installation you should consult a technician who does have this knowledge and
understanding.
Failure to follow these instructions carefully and to install the interface as
described could cause harm to the vehicle or to safety systems on the vehicle.
Interference with certain safety systems could cause harm to persons as well.
If you have any questions in this regard please call the Metra Help line at
1-844-299-3774 and for ordering questions call Metra at 1-800-221-0932.
COMPATIBLE VEHICLES……………………….…….…....3
WIRING LOCATION……………………….….….…......4-5
VSS WIRE……………………….…….…........................6
RSE WIRING…..……………………….…….…...............7
PRECAUTIONS…….................................................8
WIRING CONNECTIONS........................................9
PLUG AND PLAY HARNESS INSTALLATION……....10
TESTING OPERATION………………………….……...….11
VEHICLE REASSEMBLY CHECKLIST…………...….....12
3
.
COMPATIBLE VEHICLES
MAKE MODEL OPTIONS YEAR
INFINITI -2009 NAVIGATION OR COLOR SCREEN EX 2008
INFINITI -2013 COLOR SCREEN NO NAVIGATION EX 2010
INFINITI -2005 NAVIGATION OR COLOR SCREEN FX 2003
INFINITI -2008 NAVIGATION OR COLOR SCREEN FX 2006
INFINITI NAVIGATION OR COLOR SCREEN FX 2009
INFINITI -2013 COLOR SCREEN NO NAVIGATION FX 2010
INFINITI G -2009 NAVIGATION OR COLOR SCREEN 2007
INFINITI G -2013 COLOR SCREEN NO NAVIGATION 2010
INFINITI COLOR SCREEN NO NAVIGATION JX 2013
INFINITI M -2010 NAVIGATION OR COLOR SCREEN 2008
INFINITI M -2013 COLOR SCREEN NO NAVIGATION 2011
INFINITI -2010 NAVIGATION OR COLOR SCREEN QX 2004
INFINITI Q40 -2016 COLOR SCREEN NO NAVIGATION 2015
INFINITI Q50 -2016 COLOR SCREEN NO NAVIGATION 2015
INFINITI Q60 -2016 COLOR SCREEN NO NAVIGATION 2014
INFINITI Q70 -2016 COLOR SCREEN NO NAVIGATION 2014
INFINITI QX50 -2016 COLOR SCREEN NO NAVIGATION 2014
INFINITI QX60 -2016 COLOR SCREEN NO NAVIGATION 2014
INFINITI QX70 -2016 COLOR SCREEN NO NAVIGATION 2014
NISSAN NAVIGATION OR COLOR SCREEN 370Z 2009
NISSAN ALTIMA -2006 NAVIGATION OR COLOR SCREEN 2005
NISSAN ARMADA -2007 NAVIGATION OR COLOR SCREEN 2004
NISSAN ARMADA -2012 NAVIGATION OR COLOR SCREEN 2008
NISSAN ARMADA -2016 COLOR SCREEN NO NAVIGATION 2013
NISSAN -R -2010 NAVIGATION OR COLOR SCREEN GT 2009
NISSAN MAXIMA -2008 NAVIGATION OR COLOR SCREEN 2004
NISSAN MAXIMA NAVIGATION OR COLOR SCREEN 2009
NISSAN MAXIMA -2015 COLOR SCREEN NO NAVIGATION 2010
NISSAN MURANO -2007 NAVIGATION OR COLOR SCREEN 2003
NISSAN MURANO -2010 NAVIGATION OR COLOR SCREEN 2008
NISSAN MURANO -2014 COLOR SCREEN NO NAVIGATION 2011
NISSAN PATHFINDER -2007 NAVIGATION OR COLOR SCREEN 2005
NISSAN PATHFINDER -2012 NAVIGATION OR COLOR SCREEN 2008
NISSAN PATHFINDER -2016 COLOR SCREEN NO NAVIGATION 2013
NISSAN QUEST -2006 NAVIGATION OR COLOR SCREEN 2004
NISSAN QUEST -2009 NAVIGATION OR COLOR SCREEN 2007
NISSAN QUEST -2016 COLOR SCREEN NO NAVIGATION 2011
NISSAN TITAN -2012 NAVIGATION OR COLOR SCREEN 2004
