AXi-HA20-R INSTALLATION MANUAL
Tech Support: 844-AXX-ESSI WWW.AXXESSINTERFACES.COM
AXi-RGB1 AXi-RGB2 AXi-RGB3
PLUG & PLAY WIRING HARNESS COMPATIBLE WITH
Rev. 4.0 081915
PLEASE REVIEW THIS INSTALLATION MANUAL
CAREFULLY BEFORE BEGINNING ANY WORK
!!!DO NOT CONNECT AXI-HA20-R BEHIND NAVIGATION SCREEN, THIS
WILL DAMAGE AXXESS.i INTERFACE IMMEDIATELY!!!
2
Table Of Contents
………………………………….……….
IMPORTANT
IMPORTANT
IMPORTANT
IMPORTANT IMPORTANT WARNING
WARNING
WARNING
WARNINGWARNING
This product includes instructions for installation which must be carefully
followed. The instructions are worded in such a manner to assume that the
installer is capable of completing these type of electronic installations. If you
are unclear as to what you are instructed to do or believe that you do not
understand the instructions so as to properly and safely complete the
installation you should consult a technician who does have this knowledge and
understanding.
Failure to follow these instructions carefully and to install the interface as
described could cause harm to the vehicle or to safety systems on the vehicle.
Interference with certain safety systems could cause harm to persons as well.
If you have any questions in this regard please call the Metra Help line at
1-844-299-3774 and for ordering questions call Metra at 1-800-221-0932.
COMPATIBLE VEHICLES/WIRING LOCATIONS…....3
PRECAUTIONS.…………………………………….....……...4
WIRING CONNECTIONS……………………….…...….....5
PLUG & PLAY HARNESS INSTALLATION……...........6
TESTING OPERATION………………………….……...…..7
VEHICLE REASSEMBLY CHECKLIST…………...…......8
3
.
COMPATIBLE VEHICLES
MAKE MODEL YEAR
ACURA MDX - 2003 2006
ACURA MDX - 2007 2009
ACURA RDX - 2007 2009
ACURA RL 2004
ACURA - RL 2005 2008
ACURA - TL 2004 2008
ACURA - TSX 2004 2008
HONDA ACCORD -2003 2007
HONDA - ODYSSEY 2005 2007
HONDA PILOT - 2006 2008
HONDA RIDGELINE - 2006 2008
ACCESSORY GROUND REVERSE LOCATION
MAKE MODEL YEAR ACCESSORY GROUND REVERSE
ACURA MDX - PIN 2. WHT/RED PIN 4. BLK PIN 5. GRN/BLK 2003 2006
ACURA MDX - PIN 2. PUR PIN 4. BLK PIN 5. BRN 2007 2009
ACURA RDX - PIN 2. PUR PIN 4. BLK PIN 5. LT.BLU 2007 2009
ACURA PIN 2. WTH/YEL PIN 4. BLK PIN 5. GRN/BLK RL 2004
ACURA - PIN 2. PUR PIN 4. BLK PIN 5. BRN RL 2005 2008
ACURA - PIN 2. YEL/RED PIN 4. BLK PIN 5. GRN TL 2004 2008
ACURA - PIN 2. YEL/RED PIN 4. BLK PIN 5. GRN TSX 2004 2008
HONDA ACCORD - PIN 2. YEL/RED PIN 4. BLK PIN 5. GRN 2003 2007
HONDA ODYSSEY - PIN 2. YEL/RED PIN 4. BLK PIN 5. GRN 2005 2007
HONDA PILOT - PIN 2. WHT/RED PIN 4. BLK PIN 5. GRN/BLK 2006 2008
HONDA RIDGELINE - PIN 2. YEL/RED PIN 4. BLK PIN 5. GRN 2006 2008
Accessory, Reverse and Ground wires are found in the 8 pin connector at the navigation DVD-ROM
REAR SEAT ENTERTAINMENT VIDEO SIGNAL LOCATION
MAKE MODEL YEAR VIDEO+ VIDEO - CONNECTOR
ACURA MDX - PIN 9. BLU PIN 22. RED 26 PIN GRY CON AT DVD 2003 2006
ACURA MDX - PIN 10. BLU PIN 9. PNK 16 PIN GRN CON AT DVD 2007 2009
HONDA - PIN 5. BLU PIN 14. PNK 22 PIN GRN CON AT DVD ODYSSEY 2005 2007
HONDA PILOT - PIN 5. BLU PIN 14. PNK 22 PIN GRN CON AT DVD 2006 2008
Table.1
Table.2
