AXi-HA16P-R INSTALLATION MANUAL
Tech Support: 844-AXX-ESSI WWW.AXXESSINTERFACES.COM
AXi-RGB3 AXi-RGB2
PLUG & PLAY WIRING HARNESS COMPATIBLE WITH
Rev. 4.0 081915
PLEASE REVIEW THIS INSTALLATION MANUAL
CAREFULLY BEFORE BEGINNING ANY WORK
2
Table Of Contents
………………………………….……….
IMPORTANT
IMPORTANT
IMPORTANT
IMPORTANT IMPORTANT WARNING
WARNING
WARNING
WARNINGWARNING
This product includes instructions for installation which must be carefully
followed. The instructions are worded in such a manner to assume that the
installer is capable of completing these type of electronic installations. If you
are unclear as to what you are instructed to do or believe that you do not
understand the instructions so as to properly and safely complete the
installation you should consult a technician who does have this knowledge and
understanding.
Failure to follow these instructions carefully and to install the interface as
described could cause harm to the vehicle or to safety systems on the vehicle.
Interference with certain safety systems could cause harm to persons as well.
If you have any questions in this regard please call the Metra Help line at
1-844-299-3774 and for ordering questions call Metra at 1-800-221-0932.
COMPATIBLE VEHICLES/WIRING LOCATIONS…....3
PRECAUTIONS.…………………………………….....……...4
WIRING CONNECTIONS……………………….…...….....5
PLUG & PLAY HARNESS INSTALLATION……...........6
TESTING OPERATION………………………….……...…..7
VEHICLE REASSEMBLY CHECKLIST…………...…......8
3
.
COMPATIBLE VEHICLES
MAKE MODEL YEAR
ACURA ILX - 2013 2015
ACURA RDX - 2013 2015
ACURA - TL 2012 2014
ACCESSORY GROUND REVERSE LOCATION
MAKE MODEL YEAR ACCESSORY GROUND REVERSE
ACURA ILX - PIN 18. PUR PIN 12. BLK NOT REQIRED 2013 2015
ACURA RDX - PIN 18. PUR PIN 12. BLK NOT REQIRED 2013 2015
ACURA - PIN 18. PUR PIN 12. BLK NOT REQIRED TL 2012 2014
Table.1
Accessory and Ground wires are found in the main 24 pin connector behind radio
