AXGMLN-10
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 5/12/20 INSTAXGMLN-10
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
INTERFACE COMPONENTS
OPTIONAL ACCESSORIES (sold separately)
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties • Small flat-blade screwdriver
TABLE OF CONTENTS
Connections ............................................................2
Installation .............................................................3
Programming .........................................................3
Adjustments ...........................................................3
Troubleshooting .....................................................3
GM Data Interface 2016-Up
APPLICATIONS
CHEVROLET
Colorado (with IOB radio) 2017-Up
Cruze (with IOA radio) 2016-2018
Cruze Hatchback (with IOA radio) 2016-2018
Equinox (with IOB radio) 2018
Malibu (with IOA radio) 2016-2018
Silverado 2016-2018(with IOB radio)
Silverado 2019LD
GMC
Canyon (with IOB radio) 2017-2018
Sierra (with IOB radio) 2016-2018
Sierra Limited (with IOB radio) 2019
• AXGMLN-10 interface • AXGMLN-10 harness
• 16-pin harness with stripped leads
Extension Harness: AXEXH-GM10
Steering Wheel Control Interface: AXSWC
The IOA/IOB code, if applicable, can be found in the label located:Service Parts Identification
Glovebox: Canyon/Colorado/Cruze/Equinox/Silverado/Sierra – Rear Compartment Floor: Malibu
INTERFACE FEATURES
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains chimes
• Pre-wired AXSWC harness (AXSWC sold separately)
• Retains OnStar / OE Bluetooth
• Retains the factory backup camera†
• Adjustable chime/OnStar level
• Can be used in both amplified and non-amplified models (excluding Bose)
• Retains balance and fade
• Micro-B USB updatable
† Excluding 2018 trucks
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date vehicle
specific applications
2
CONNECTIONS
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the wire to the accessory wire.Red
If installing an AXSWC (sold separately), there will be an accessory wire on the Note:
AXGMLN-10 harness to connect as well.
• If
the vehicle is equipped with a factory amplifier (excluding Bose), connect the wire Blue/White
to the amp turn on wire. This wire must be connected to hear sound from the factory amplifier
.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
• If the aftermarket radio has a mute wire, connect the wire to it. If the mute wire is Brown
not connected, the radio will turn off when OnStar is activated.
• Connect the wire to the right front positive speaker output.Gray
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
• Tape off and disregard the following (4) wires, they will not be used in this application.
Green Green/Black Purple Purple/Black, , ,
From the AXGMLN-10 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• If installing an AXSWC (sold separately), connect the wire to accessory power.Red
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative speaker output.Purple/Black
•
The Black/Yellow wire is used for OnStar level adjustment for models that do not come equipped
with steering wheel controls. See the OnStar level Adjustment section for further instructions
.
•
If retaining the factory backup camera, connect the Yellow RCA jack to the reverse camera input
.
12-pin AXSWC harness & 3.5mm jack:
The 12-pin AXSWC harness & 3.5mm jack are to be used with an AXSWC (sold separately) to
retain steering wheel audio controls. If the AXSWC is not being used, disregard this harness and
3.5mm jack. If it is to be used, please refer to the AXSWC instructions for radio connections and
programming. Disregard the harness that comes with the AXSWC.
Note: The relay attached to the AXGMLN-10 harness is only for audible turn signal clicks. No extra
steps are required to retain this feature, so leave the relay as-is.
3
REV. 5/12/2020 INSTAXGMLN-10
With the key in the off position:
1. Connect the , and the 16-pin harness with stripped leads AXGMLN-10 harness, into the
AXGMLN-10 interface.
2. If an AXSWC (sold separately) will be used, do not connect it until the AXGMLN-10 is
programmed and fully functional.
Attention! AXGMLN-10 harness Do not connect the to the wiring harness in the vehicle just yet.
For the steps below, the L.E.D. located inside the AXGMLN-10 interface can only be seen while
active. The interface does not need to be opened to see the L.E.D.
1. Start the vehicle.
2. Connect the AXGMLN-10 harness to the wiring harness in the vehicle. The L.E.D. will initially
be to indicate the interface is powered.Green
For the Equinox and Malibu, use part number Note: AXEXH-GM10 (sold separately) to extend
the wiring harness to the right of the glovebox where the radio brain is located at.
3.
After a few seconds the L.E.D. will turn on solid while the interface automatically programs Red
to the vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds
.
4. After the interface is programmed, the L.E.D. will turn on solid Green, and the radio will
come back on, indicating programming was successful.
5. Test all functions of the installation for proper operation, before reassembling the dash.
Note: The vehicle must be running for the factory camera to power on.
6. If the interface fails to function, refer to the Troubleshooting section.
Resetting the AXGMLN-10 Interface
1. The reset button is located inside the interface, between the two connectors. The Blue
button is accessible outside the interface, no need to open the interface.
2. Press and hold the reset button for two seconds, then let go to reset the interface.
3. Refer to the section from this point.Programming
Chime Level Adjustment:
1. With the vehicle on, turn it off and leave the keys in ignition. Open the driver’s door;
chimes will be heard.
2. Wait 10 seconds, and then with a small flat-blade screwdriver, turn the potentiometer
clockwise to raise the chime level; counterclockwise to lower the chime level.
3. When the chime is at a desired level, remove the keys from the ignition. This will lock the
chime volume at its current level.
OnStar Level Adjustment:
1. Press the OnStar button to activate it.
2. While OnStar is speaking, press the VOLUME UP VOLUME DOWN or buttons on the steering
wheel to raise or lower the OnStar level.
3.
If the vehicle does not come equipped with steering wheel controls, locate the Black/Yellow
wire from the AXGMLN-10 harness.
4. While OnStar is speaking, tap the Black/Yellow wire to ground. Once the OnStar level is
set, it will stay at that level until the Black/Yellow wire is tapped to ground again.
INSTALLATION
PROGRAMMING
TROUBLESHOOTING
ADJUSTMENTS
