Installation instructions for part AXGMLN-08

REV. 5/6/2020 INSTAXGMLN-08

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power

(12-volt 10-amp)

• Retains R.A.P. (retained

accessory power)

• Provides NAV outputs (parking

brake, reverse, and speed sense)

• Retains chimes

• Retains OnStar/OE Bluetooth

• Adjustable OnStar level

• Designed for non-amplified

models, or when bypassing

a factory amp

• Retains balance and fade

• AXUSB-CBL updatable

(sold separately)

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

AXGMLN-08

GM Data Interface

2012-2016

APPLICATIONS

• AXGMLN-08 interface • AXGMLN-08 harness

• 16-pin harness with stripped leads

INTERFACE COMPONENTS

Connections to be made 2 ...................................................

Installing the AXGMLN-08 3 ................................................

Initializing the AXGMLN-08 3 ..............................................

Adjusting the AXGMLN-08 3 ................................................

Table of Contents

CHEVROLET

Avalanche † * 2012-2013

Express † 2013-2015

Malibu (with single color,

monochrome

display) * 2013-2015

Malibu Limited (

with single color,

monochrome display) * 2016

CHEVROLET (CONT)

Silverado 2500/3500 † * 2014

Silverado † * 2012-2013

Suburban † * 2012-2014

Tahoe † * 2012-2014

Trax * 2015-2016

GMC

Savana † 2013-2015

Sierra 2500/3500 † * 2014

Sierra † * 2012-2013

Yukon/Yukon XL † * 2012-2014

* These vehicles have an amplifier option. Please reference the “Service Parts Identification” sticker located in the

glove box for the RPO code UQ7 or Y91. If UQ7 or Y91 are present, then the vehicle is equipped with an amplifier.

Either use the AXGMLN-07 interface, or bypass the amplifier.

† Only for models with NAV.

AXGMLN-08

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

Note: If installing an AXSWC (sold separately), there will be an accessory wire

there to connect as well.

• If the aftermarket radio has an illumination wire, connect the Orange/White

wire to it.

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

The following (3) wires are only for multimedia/navigation radios that require

these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wireLight Green

From the AXGMLN-08 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative output.Purple/Black

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. Refer to the OnStar level

Adjustment section for further instructions.

12-pin pre-wired AXSWC harness:

• This harness is to be used along with the optional AXSWC (not included) to

retain steering wheel audio controls. If the AXSWC is not being used, disregard

this harness. If it will be used, please refer to the AXSWC instructions for radio

connections and programming.

Note: Disregard the harness that comes with the AXSWC.

• Connect the wire to the accessory wire.Red

Note: The relay attached to the AXGMLN-08 harness is only for audible turn

signal clicks. No extra steps are required to retain this feature, so leave the

relay as-is.

Connections to be made

AXGMLN-08

With the key in the off position:

• Connect the 16-pin harness with stripped leads, and the AXGMLN-08 harness,

into the interface.

• Connect the AXGMLN-08 harness to the wiring harness in the vehicle.

Note: If using the AXSWC, connect it after you initialize and test the

AXGMLN-08, with the key in the off position.

OnStar Level Adjustment

• Press the OnStar button to activate it.

• While OnStar is speaking, press the VOLUME UP or VOLUME DOWN button on

the steering wheel to raise or lower the OnStar level.

• If the vehicle does not come equipped with steering wheel controls, locate the

Black/Yellow

wire on the AXGMLN-08 harness.

•

While OnStar is speaking, tap the Black/Yellow wire to ground. Once the OnStar level

is set, it will stay at that level until the Black/Yellow wire is tapped to ground again

Attention! If the interface loses power for any reason, the following steps will need

to be performed again. Also, if installing an AXSWC connect it after you initialize and

test the interface/radio, with the key in the off position.

• Turn the key (or push-to-start button) to the ignition position and wait until the

radio comes on.

Note: If the radio does not come on within 60 seconds, turn the key to the

off position, disconnect the interface, check all connections, reconnect the

interface, and then try again.

• Turn the key to the off position, and then to the accessory position. Test all

functions of the installation for proper operation, before reassembling the dash.

Initializing the AXGMLN-08

Installing the AXGMLN-08 Adjusting the AXGMLN-08
