Installation instructions for part AXGMLN-04

REV. 1/21/2020 INSTAXGMLN-04

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Retains chimes

• Pre-wired AXSWC harness (AXSWC sold

separately)

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Designed for amplified models

• Retains balance and fade

• AXUSB-CBL (sold separately) updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

TOOLS REQUIRED

AXGMLN-04

GM Data Interface

2006-2012

APPLICATIONS

• AXGMLN-04 interface • AXGMLN-04 harness

• 16-pin harness with stripped leads

INTERFACE COMPONENTS

Connections to be made .........................................2

Installing the AXGMLN-04 ......................................3

Initializing the AXGMLN-04 ....................................3

Adjusting the AXGMLN-04 ......................................3

Table of Contents

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G6 2010

G6 (5th digit of VIN must

be a J, K, or L) 2009

G5 2007-2009

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2007-2009

AXGMLN-04

Connections to be made

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

Note: If installing an AXSWC (sold separately), there will be an accessory wire

there to connect as well.

• Connect the wire to the amp turn on wire. This wire must be Blue/White

connected to hear sound from the factory amplifier.

•

If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

From the AXGMLN-04 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. Refer to the OnStar level

Adjustment section for further instructions.

Note: The relay attached to the AXGMLN-04 harness is only for audible turn signal

clicks. No extra steps are required to retain this feature, so leave the relay as-is

12-pin pre-wired AXSWC harness:

•

This harness is to be used along with the optional AXSWC (not included) to retain steering

wheel audio controls. If the AXSWC is not being used, disregard this harness. If it will be

used, please refer to the AXSWC instructions for radio connections and programming.

Note: Disregard the harness that comes with the AXSWC.

• Connect the wire to the accessory wire.Red

• The following wire must be cut before programming the AXSWC:

• For the following vehicles cut the wire. If your vehicle is not Green/Orange

listed, do not cut anything:

CHEVROLET

HHR 2006-2009

Malibu 2008-2012

PONTIAC

G5 2007-2009

G6 2010

G6 (5th digit of VIN must

be a J, K, or L) 2009

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2006-2009

AXGMLN-04

Installing the AXGMLN-04

With the key in the off position:

• Connect the 16-pin harness with stripped leads, and the AXGMLN-04 harness,

into the interface.

• Connect the AXGMLN-04 harness to the wiring harness in the vehicle.

Note: If using the AXSWC, connect it after you initialize and test the

AXGMLN-04, with the key in the off position.

Initializing the AXGMLN-04

Attention! If the interface loses power for any reason, the following steps will need

to be performed again. Also, if installing an AXSWC, connect it after you initialize

and test the interface/radio, with the key in the off position.

• Turn the key (or push-to-start button) to the ignition position and wait until the

radio comes on.

Note: If the radio does not come on within 60 seconds, turn the key to the

off position, disconnect the interface, check all connections, reconnect the

interface, and then try again.

• Turn the key to the off position, pause for a moment, and then to the accessory

position. Test all functions of the installation for proper operation, before

reassembling the dash.

Adjusting the AXGMLN-04

Audio level adjustment:

• With the vehicle and radio turned on, turn the volume up 3/4 of the way.

• With a small flat-blade screwdriver, adjust the potentiometer clockwise to raise

the audio level; counterclockwise to lower the audio level.

• Once at a desired level, audio level adjustment is complete.

Chime level adjustment:

• With the vehicle on, turn it off and leave the keys in ignition. Open the driver’s

door; chimes will be heard.

• Wait 10 seconds, and then with a small screwdriver, turn the potentiometer

clockwise to raise the chime level; counterclockwise to lower the chime level.

• When the chime is at a desired level, remove the keys from the ignition. This

will lock the chime volume at its current level.

OnStar Level Adjustment:

• Press the OnStar button to activate it.

• While OnStar is speaking, press the VOLUME UP or VOLUME DOWN button on

the steering wheel to raise or lower the OnStar level.

• If the vehicle does not come equipped with steering wheel controls, or they no

longer function, locate the Black/Yellow wire on the AXGMLN-04 harness.

• While OnStar is speaking, tap the Black/Yellow wire to ground. Once the

OnStar level is set, it will stay at that level until the Black/Yellow wire is tapped

to ground again.
