Installation instructions for part AXGMLN-01
REV. 8/6/2020 INSTAXGMLN-01
axxessinterfaces.com • metraonline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake,
reverse, speed sense)
• Pre-wired AXSWC harness (AXSWC sold
separately)
• Retains chimes to the factory speaker
• Adjustable chime level
• Retains OnStar / OE Bluetooth
• Adjustable OnStar level
• Retains the factory backup camera
• Designed for non-amplified models, or
when bypassing a factory amp
• Retains balance and fade
• Includes an antenna adapter
• AXUSB-CBL updatable (sold separately)
INTERFACE FEATURES
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
• Small flat-blade screwdriver
TOOLS REQUIRED
AXGMLN-01
GM Data Interface
2006-Up
• AXGMLN-01 interface • AXGMLN-01 harness
• 16-pin harness with stripped leads • Backup camera harness • Antenna adapter
INTERFACE COMPONENTS
Connections to be made 2-3 ................................................
Installing the AXGMLN-01 3 ................................................
Initializing the AXGMLN-01 3 ..............................................
Adjusting the AXGMLN-01 4 ................................................
Table of Contents
APPLICATIONS
See inside front cover
AXGMLN-01
Applications
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the wire to the accessory wire.Red
Note: If installing an AXSWC (sold separately), there will be an accessory wire
there to connect as well.
• If the aftermarket radio has an illumination wire, connect the Orange/White
wire to it.
• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown
mute wire is not connected, the radio will turn off when OnStar is activated.
• Connect the wire to the right front positive speaker output.Gray
• Connect the wire to the right front negative speaker output.Gray/Black
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
The following (3) wires are only for multimedia/navigation radios that require these wires
.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
Connections to be made
† These vehicles are standard for a factory amplifier. Either use the AXGMLN-02 interface,
or bypass the amplifier.
‡ Only for models without NAV in 2011-2015. For models with NAV, use the AXGMLN-08.
∆ Only for models without NAV in 2012-up. For models with NAV, use the AXGMLN-08.
BUICK
Enclave 2008-up
Lucerne 2006-2011
CADILLAC
DTS † 2006-2011
Escalade † 2007-2014
SRX † 2007-2009
CHEVROLET
Avalanche ∆ 2007-2013
Captiva Sport 2012-2015
Equinox 2007-2009
Express ‡ 2008-up
Impala 2006-2013
Impala Limited 2014-2016
Monte Carlo 2006-2007
Silverado (new body) ∆ 2007-2013
Silverado 2500/3500 ∆ 2014
Suburban ∆ 2007-2014
Tahoe ∆ 2007-2014
Traverse 2009-up
GMC
Acadia 2007-2016
Acadia Limited 2017
Savana ‡ 2008-up
Sierra 2500/3500 ∆ 2014
Sierra (new body) ∆ 2007-2013
Yukon / Yukon XL ∆ 2007-2014
HUMMER
H2 † 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
Vue 2008-2010
SUZUKI
XL-7 2007-2009
AXGMLN-01
Connections to be made
From the AXGMLN-01 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative speaker output.Purple/Black
• The Black/Yellow wire is used for OnStar level adjustment for models that
do not come equipped with steering wheel controls. See the OnStar level
Adjustment section for further instructions.
12-pin pre-wired AXSWC harness:
• This harness is to be used along with the optional AXSWC (not included)
to retain steering wheel audio controls. If the AXSWC is not being used,
disregard this harness. If it will be used, please refer to the AXSWC
instructions for radio connections and programming.
Note: Disregard the harness that comes with the AXSWC.
• Connect the wire to the accessory wire.Red
Note: The relay attached to the AXGMLN-01 harness is only for audible turn signal
clicks. No extra steps are required to retain this feature, so leave the relay as-is
.
Backup camera harness (if applicable):
• If retaining the factory backup camera, connect the Yellow RCA jack to the
backup camera input of the aftermarket radio.
With the key in the off position:
• Connect the 16-pin harness with stripped leads, and the AXGMLN-01 harness,
into the interface.
• Connect the AXGMLN-01 harness to the wiring harness in the vehicle.
• If using the AXSWC, connect it after you initialize and test the AXGMLN-01, with
the key in the off position.
• If applicable, connect the backup camera harness to the wiring harness in the
vehicle. This harness is located behind the radio.
Attention! If the interface loses power for any reason, the following steps will need
to be performed again. Also, if installing an AXSWC connect it after you initialize and
test the interface/radio, with the key in the off position.
• Turn the key (or push-to-start button) to the ignition position and wait until the
radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the
off position, disconnect the interface, check all connections, reconnect the
interface, and then try again.
• Turn the key to the off position, pause for a moment, and then to the accessory
position. Test all functions of the installation for proper operation, before
reassembling the dash.
Installing the AXGMLN-01
Initializing the AXGMLN-01
