Installation instructions for part AXGM-09

REV. 1/20/2020 INSTAXGM-09

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

•

Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Retains chimes

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Designed for amplified models

• Retains balance and fade

• AXUSB-CBL (sold separately) updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

TOOLS REQUIRED

AXGM-09

GM Data Interface

2001-2005

• AXGM-09 interface • AXGM-09 harness

• 16-pin harness with stripped leads

INTERFACE COMPONENTS

Connections to be made .........................................2

Installing the AXGM-09 ..........................................3

Initializing the AXGM-09 ........................................3

Adjusting the AXGM-09 ..........................................3

Table of Contents

APPLICATIONS

OLDSMOBILE

Aurora 2001-2003

PONTIAC

Bonneville 2000-2005

AXGM-09

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

• Connect the wire to the amp turn on wire. This wire must be Blue/White

connected to hear sound from the factory amplifier.

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wireLight Green

• Tape off and disregard the following (1) wire, it will not be used in this

application: .Orange/White

From the AXGM-09 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the power antenna wire.Blue

• If the aftermarket radio has an illumination wire, connect the wire to it.Orange

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. Refer to the OnStar level

Adjustment section for further instructions.

• Cut and tape off the appropriate wire on the 32-pin harness:Blue/White

• For model years 2000-2001 cut pin-A6.

• For model years 2002-2005 cut pin-A3.

Connections to be made

AXGM-09

Installing the AXGM-09

With the key in the off position:

• Connect the 16-pin harness with stripped leads, and the AXGM-09 harness, into

the interface.

• Connect the AXGM-09 harness to the wiring harness in the vehicle.

Initializing the AXGM-09

Attention! If the interface loses power for any reason, the following steps will need

to be performed again.

• Turn the key (or push-to-start button) to the ignition position and wait until the

radio comes on.

Note: If the radio does not come on within 60 seconds, turn the key to the

off position, disconnect the interface, check all connections, reconnect the

interface, and then try again.

• Turn the key to the off position, pause for a moment, and then to the accessory

position. Test all functions of the installation for proper operation, before

reassembling the dash.

Adjusting the AXGM-09

Audio level adjustment:

• With the vehicle and radio turned on, turn the volume up 3/4 of the way.

• With a small flat-blade screwdriver, adjust the potentiometer clockwise to

raise the audio level; counterclockwise to lower the audio level.

• Once at a desired level, audio level adjustment is complete.

Chime level adjustment:

• With the vehicle on, turn it off and leave the keys in ignition. Open the driver’s

door; chimes will be heard.

• Wait 10 seconds, and then with a small screwdriver, turn the potentiometer

clockwise to raise the chime level; counterclockwise to lower the chime level.

• When the chime is at a desired level, remove the keys from the ignition. This

will lock the chime volume at its current level.

OnStar Level Adjustment:

• Press the OnStar button to activate it.

• While OnStar is speaking, press the VOLUME UP or VOLUME DOWN button on

the steering wheel to raise or lower the OnStar level.

• If the vehicle does not come equipped with steering wheel controls, or they no

longer function, locate the Black/Yellow wire on the AXGM-09 harness.

•

While OnStar is speaking, tap the Black/Yellow wire to ground. Once the

OnStar level is set, it will stay at that level until the Black/Yellow wire is

tapped to ground again
