Installation instructions for part AXGM-07

REV. 1/20/2020 INSTAXGM-07

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt

10-amp)

• Retains R.A.P. (retained accessory

power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Retains chimes to the factory speaker

• Adjustable chime level

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Designed for non-amplified models,

or when bypassing a factory amp *

• Retains balance and fade

• USB-CAB updatable (sold separately)

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

TOOLS REQUIRED

AXGM-07

GM Data Interface

2005-2006

APPLICATIONS

• AXGM-07 interface • AXGM-07 harness

• 16-pin harness with stripped leads

INTERFACE COMPONENTS

Connections to be made 2 ...................................................

Installing the AXGM-07 3 ....................................................

Initializing the AXGM-07 3 ..................................................

Adjusting the AXGM-07 3 ....................................................

Table of Contents

CHEVROLET

Equinox 2005-2006

PONTIAC

Torrent 2006

* If the vehicle is amplified, either use the AXGM-08 interface, or bypass the amplifier. If

bypassing the amplifier, follow the “Axxess Interface Amp Bypass Schematic” online.

AXGM-07

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

• If the aftermarket radio has an illumination wire, connect the Orange/White

wire to it.

Note: If the wire on the AXGM-07 harness is populated on the factory Orange

side, use that wire instead.

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

Connections to be made

From the AXGM-07 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the power antenna wire.Blue/White

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. See the OnStar level

Adjustment section for further instructions.

AXGM-07

Installing the AXGM-07

Initializing the AXGM-07

With the key in the off position:

• Connect the 16-pin harness with stripped leads, and the AXGM-07 harness, into

the interface.

• Connect the AXGM-07 harness to the wiring harness in the vehicle.

Attention! If the interface loses power for any reason, the following steps will need

to be performed again. Also, if installing an AXSWC connect it after you initialize and

test the interface/radio, with the key in the off position.

• Turn the key (or push-to-start button) to the ignition position and wait until the

radio comes on.

Note: If the radio does not come on within 60 seconds, turn the key to the

off position, disconnect the interface, check all connections, reconnect the

interface, and then try again.

• Turn the key to the off position, and then to the accessory position. Test all

functions of the installation for proper operation, before reassembling the dash.

Adjusting the AXGM-07

Chime level adjustment:

• Turn the vehicle off but leave the keys in the ignition. Open the driver’s door and

leave it open; chimes will be heard.

• Wait 10 seconds, and then with a small flat-blade screwdriver, adjust the

potentiometer clockwise to raise the chime level; counterclockwise to lower the

chime level.

Note: The potentiometer is located on the side of the interface where the 16-

pin harness with stripped leads is connected to.

• When the chime is at the desired level, remove the keys from the ignition. This

will lock the chime level in at its current level.

OnStar level adjustment:

• Press the OnStar button to activate it.

• While OnStar is speaking, press the VOLUME UP or VOLUME DOWN buttons on

the steering wheel to raise or lower the OnStar level.

• If the vehicle does not come equipped with steering wheel controls, locate the

Black/Yellow wire on the AXGM-07 harness.

• While OnStar is speaking, tap the Black/Yellow wire to ground. Once the

OnStar level is set, it will stay at that level until the Black/Yellow wire is tapped

to ground again.
