AXDSPX-CH3
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com Ā© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 7/30/20 INSTAXDSPX-CH3
Google Play Store Apple App Store
iOS 12.1 or higher
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
ā€¢ Crimping tool and connectors, or solder gun,
solder, and heat shrink ā€¢ Tape ā€¢ Wire cutter
ā€¢ Zip ties ā€¢ Multimeter
TABLE OF CONTENTS
Installation Options ...............................................2
Installation .............................................................2
Connections ........................................................ 3-4
Mobile App ........................................................ 5-13
Speciļ¬cations ....................................................... 14
Chrysler DSP Interface With Pre-Wired
Harness 2011-2018
ā€¢ Includes a DSP (Digital Signal Processor)
ā€¢ 31 Band graphic EQ
ā€¢ 10 individually assignable outputs
ā€¢ Independent equalization on each of the 10 outputs
ā€¢ Independent high pass, low pass, and bandpass ļ¬lters
ā€¢ Each channel can be delayed independently up to 10ms
ā€¢ Clipping detection and limiting circuits
ā€¢ Retains factory parking sensor chimes
ā€¢ Retains U-Connect voice prompts
ā€¢ Adjustable chime level
ā€¢ Can be used in ampliļ¬ed and non-ampliļ¬ed models
ā€¢ Easy behind the radio installation with pre-wired harness
ā€¢ Bass knob included for level control of subwoofer amp
ā€¢ Settings adjusted via BluetoothĀ® in a smart device application (tablet
or mobile phone), compatible with both Android and Apple devices
ā€¢ Read, write, and store conļ¬gurations for future recall
ā€¢ Password protect feature available in the mobile app
ā€¢ Micro-B USB updatable
ā€¢ AXDSPX-CH3 interface
ā€¢ AXDSPX-CH3 interface harness
ā€¢ AXDSPX-CH3 vehicle T-harness ā€¢ Bass knob
APPLICATIONS
Visit axxessinterfaces.com for current application list
2
Adding a sub to a factory system:
This feature offers the ability to add a subwoofer to a factory system, whether ampliļ¬ed or non-
ampliļ¬ed. (refer to page 3)
Adding a full-range amp & sub to a factory system:
This feature offers the ability to add a full-range amp and sub to a factory system, whether
ampliļ¬ed ā€  or non-ampliļ¬ed. (refer to page 4)
ā€  For ampliļ¬ed models the amp must be bypassed/unplugged, and chosen in With OE Ampliļ¬er
the Conļ¬guration Vehicle Type tab under . Use Axxess AXABH-CH2 (sold separately) to bypass the
amp for best results.
Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing
multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all amps
combined exceeds 1-amp. Use Metra part number E-123 (sold separately) for best results.
1. Remove the factory radio ā€ , then unplug all connectors.
2. Install the AX-DSPX-CH3 vehicle T-harness to the vehicle and make all necessary
connections, but leave the amp turn-on wire disconnected.
3. AX-DSPX-CH3 vehicle T-harness AX-DSPX-CH3 interface Plug the to the .
4. Plug the AX-DSPX-CH3 interface harness to the AX-DSPX-CH3 interface.
5. Download and install the AXDSP-X app from the Google Play Store Apple App or
Store.
6. Bluetooth Connection Open the app then select the tab. Follow the instructions to
pair the mobile device to the interface. Refer to page 6 for more information.
7. Scroll to the Conļ¬guration tab then select the vehicle type. Press the ā€” Lock Down
button to save the conļ¬guration. Refer to page 7 for more information.
8. Connect the amp turn-on wire.
9. Adjust the settings in the app as desired. Press the ā€” button to save any Lock Down
new conļ¬gurations.
ā€  Refer to Metra online for dash disassembly. If Metra makes a dash kit for the vehicle,
disassembly will be within those instructions.
ā€” Anytime the interface is locked down the key must be cycled off then back on
INSTALLATION OPTIONS INSTALLATION
3
REV. 7/30/2020 INSTAXDSPX-CH3
Factory Radio
Keep Connected
Any remaining wires
tape off and disregard
Black - Ground
Orange - Control
Bass Knob
Factory Radio Harness
Interface
Any remaining wires
tape off and disregard
Vehicle T-Harness
Blue/White - Amp Turn-On Wire
These outputs can be used for
additional sub amps, or for adding
onto the em at a later datesyst
RCA Jacks
(sold separately)
ADDING A SUB TO A FACTORY SYSTEM
