AXDSP-X
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/30/2020 INSTAXDSP-X
Google Play Store Apple App Store
iOS 12.1 or higher
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties • Multimeter
TABLE OF CONTENTS
Preface ....................................................................2
Installation Options ...............................................2
Installation .............................................................3
Connections ........................................................ 4-7
AXDSP-X app .....................................................8-17
Pinout ....................................................................18
Specifications ....................................................... 19
Axxess 10-Channel Digital Signal Processor
• 31 Band graphic EQ
• 6 Inputs, 10 individually assignable outputs
• Independent equalization on each of the 10 outputs
• Independent high pass, low pass, and bandpass filters
• Each channel can be delayed independently up to 10ms
• Chime control for GM/Chrysler vehicles
• Clipping detection and limiting circuits
• Bass knob included
• Retains OE voice prompts (SYNC® and OnStar®)
• Retains factory chimes including parking sensor and cross path
detection alerts
•
Settings adjusted via Bluetooth® in a smart device application (tablet
or mobile phone), compatible with both Android and Apple devices
• Read, write, and store configurations for future recall
• Password protect feature available in the mobile app
• Micro-B USB updatable
• AXDSP-X interface
• AXDSP-X harness (16-pin & 20-pin)
2
Aftermarket radio system:
The AXDSP-X can be used with an aftermarket radio to improve the overall listening
experience for car audio enthusiasts. Installers will connect the RCA inputs from the AXDSP-X
to the outputs from the aftermarket radio; , , (sub is optional). Front Rear Sub
(refer to page 4)
Adding a subwoofer to an existing radio:
This feature offers the Installer the ability to add an aftermarket subwoofer to an existing
radio. (refer to page 5)
Full range system to an existing radio:
This option allows the Installer to wire the AXDSP-X directly to the speaker outputs from an
existing radio for a full range audio signal (high-level).
(refer to page 6)
PREFACE INSTALLATION OPTIONS
In the following section, , choose the installation type, then either click on Installation Options
the hyperlink, or reference the page number.
The AXDSP-X provides a 12v 1-amp output to turn on an aftermarket amplifier. If installing
multiple amplifiers, an SPDT automotive relay will be required if the current exceeds that
amount. Use Metra part number E-123 (sold separately) for best results.
The AXDSP-X can also grow as your stereo system grows. Start off by adding a subwoofer, then
add on from there. Simply reference the page to change the AXDSP-X to the Installation Options
new system. All 10 channels of the AXDSP-X can be assigned however needed for the installation
at hand. If 10 channels of a subwoofer signal is needed, the AXDSP-X can do it.
3
REV. 1/30/2020 INSTAXDSP-X
INSTALLATION
1. Complete all necessary connections to the radio and vehicle, but leave the amp turn-on
wire disconnected.
2. Plug the 20-pin AXDSP-X harness into the AXDSP-X.
3. Plug the 16-pin AXDSP-X harness into the AXDSP-X.
4. Download and install the AXDSP-X app from the or Google Play Store Apple App Store.
5. Using the app, select the vehicle.
6. Connect the amp turn-on wire from the AXDSP-X.
7.
Adjust the DSP settings in the app as desired. Refer to the instructions starting on (page 7)
for an explanation of each tab in the app. (refer to page 7)
