AXDIS-GMLN29
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com Ā© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 8/6/20 INSTAXDIS-GMLN29
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
ā€¢ Wire cutter ā€¢ Crimp tool ā€¢ Solder gun ā€¢ Tape ā€¢ Connectors (example: butt-connectors, bell caps, etc.) ā€¢ Small ļ¬‚at-blade screwdriver
TABLE OF CONTENTS
Connections ........................................................3-6
- For models
without
an ampliļ¬er ....................... 3
- For models
with
an analog ampliļ¬er ................4
- For models
with
a digital ampliļ¬er ................... 5
- 3.5mm jack steering wheel control retention ...6
Installation .............................................................6
Programming ......................................................... 7
Adjustments ........................................................... 7
Extra features .........................................................8
Steering wheel control settings .......................9-11
- L.E.D. feedback ....................................................9
- Changing radio type ...........................................9
- Remapping the steering wheel control buttons ...10
- Dual assignment instructions (long button press) ...11
Troubleshooting ....................................................12
GM Data Interface with SWC 2006-Up
ā€¢ Provides accessory power
(12-volt 10-amp)
ā€¢ Retains R.A.P. (retained
accessory power)
ā€¢ Provides NAV outputs (parking
brake, reverse, speed sense)
ā€¢ Retains chimes
ā€¢ Retains audio controls on the
steering wheel
ā€¢ Retains OnStar / OE Bluetooth
ā€¢ Adjustable OnStar level
ā€¢ Retains the factory AUX-IN jack
ā€¢
Retains the factory backup camera
ā€¢
Retains RSE (rear seat entertainment)
ā€¢ Retains SAT (satellite radio)
ā€¢ Can be used in non-ampliļ¬ed, or
analog/digital ampliļ¬ed models
ā€¢
Retains balance and fade (excluding
digital ampliļ¬ed models)
ā€¢ Includes an antenna adapter
ā€¢ Micro-B USB updatable
ā€¢ AXDIS-GMLN29 interface ā€¢ AXDIS-GMLN29 harness
ā€¢ 16-pin harness with stripped leads ā€¢ 4-pin to 4-pin resistor pad harness
ā€¢ Female 3.5mm connector with stripped leads
ā€¢ Backup camera harness ā€¢ RSE harness ā€¢ Antenna adapter
APPLICATIONS
See inside front cover
2
APPLICATIONS
BUICK
Enclave 2008-2017
Lucerne 2006-2011
CADILLAC
DTS ā€  2006-2011
Escalade ā€  2007-2014
SRX ā€  2007-2009
CHEVROLET
Avalanche * 2007-2013āˆ†
Captiva Sport 2012-2015
CHEVROLET (CONT)
Equinox 2007-2009
Express ā€” 2008-Up
Impala 2006-2013
Impala
Limited
2014-2016
Monte Carlo 2006-2007
Silverado 2500/3500 * 2014āˆ†
Silverado (new body) * 2007-2013 āˆ†
Suburban ** 2007-2014āˆ†
Tahoe ** 2007-2014āˆ†
Traverse 2009-2017
GMC
Acadia 2007-2016
Acadia
Limited
2017
Savana ā€” 2008-Up
Sierra 2500/3500 * 2014āˆ†
Sierra (new body) * 2007-2013āˆ†
Yukon / Yukon XL ** 2007-2014āˆ†
HUMMER
H2 ā€  2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
Vue 2008-2010
SUZUKI
XL-7 2007-2009
* These vehicles have a digital amp option. Please reference the ā€œService Parts Identiļ¬cationā€ sticker located in the glove box for the RPO code Y91. If Y91 is present, then
the vehicle is equipped with a digital ampliļ¬er.
** These vehicles have a digital amp option. Please reference the ā€œService Parts Identiļ¬cationā€ sticker located in the glove box for the RPO code STZ or Y91. If STZ or Y91 is
present, then the vehicle is equipped with a digital ampliļ¬er.
ā€  These vehicles are standard for a digital ampliļ¬er.
ā€” For 2013-2015 models equipped with NAV use the AXDIS-GMLN44.
āˆ† For 2012-up models equipped with NAV use the AXDIS-GMLN44.
3
REV. 8/6/2020 INSTAXDIS-GMLN29
CONNECTIONS
Attention! This interface will work with models that are either non-ampliļ¬ed, analog ampliļ¬ed,
or digital ampliļ¬ed. Please follow the instructions carefully for your model vehicle. Failure to
do so will result in either no sound, or low sound. If you are unsure if your vehicle is factory
ampliļ¬ed or not, please contact your local dealership.
For models
without
an ampliļ¬er:
From the 16-pin harness with stripped leads to the aftermarket radio:
ā€¢ Connect the wire to the accessory wire.Red
ā€¢ Connect the wire to the power antenna wire.Blue/White
ā€¢ If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White
ā€¢ If the aftermarket radio has a mute wire, connect the Brown wire to it. If the mute wire is
not connected, the radio will turn off when OnStar is activated.
ā€¢ Connect the wire to the right front positive speaker output.Gray
ā€¢ Connect the Gray/Black wire to the right front negative speaker output.
ā€¢ Connect the wire to the left front positive speaker output.White
ā€¢ Connect the wire to the left front negative speaker output.White/Black
The following (3) wires are only for multimedia/navigation radios that require these wires.
ā€¢ Connect the wire to the VSS/speed sense wire.Blue/Pink
ā€¢ Connect the wire to the reverse wire.Green/Purple
ā€¢ Connect the Light Green wire to the parking brake wire
ā€¢ Tape off and disregard the following (4) wires, they will not be used in this application:
Green Green/Black Purple Purple/Black, , and .
From the AXDIS-GMLN29 harness to the aftermarket radio:
ā€¢ Connect the wire to the ground wire.Black
ā€¢ Connect the Yellow wire to the battery wire.
ā€¢ Cut off the resistors from the , , , and wires below the Green Green/Black Purple Purple/Black
heat shrink.
ā€¢ Connect the wire to the left rear positive speaker output.Green
ā€¢ Connect the wire to the left rear negative speaker output.Green/Black
ā€¢ Connect the wire to the right rear positive speaker output.Purple
ā€¢ Connect the wire to the right rear negative speaker output.Purple/Black
ā€¢ Ensure the (2) 4-pin Molex connectors are connected together.
Note:
The 4-pin to 4-pin resistor pad harness will not be used in this application.
ā€¢ The Black/Yellow wire is used for OnStar level adjustment for models that do not come
equipped with steering wheel controls. Refer to the OnStar level Adjustment section for
further instructions.
ā€¢ Connect the and RCA jacks to the audio AUX-IN jacks of the aftermarket radio.Red White
ā€¢ Disregard the DIN jack and wire.Red
Note:
The relay attached to the AXDIS-GMLN29 harness is only for audible turn signal clicks. No
extra steps are required to retain this feature, so leave the relay as-is.
Continue to 3.5mm jack steering wheel control retention
