CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AXDIS-GMLN11

I N S TA L L A T I O N I N S T R U C T I O N S

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell

caps, etc.) • Small ﬂat-blade screwdriver

TABLE OF CONTENTS

Connections to be made ................................... 2-4

- For models

without

an ampliﬁer .......................2

- For models

with

an analog ampliﬁer ................3

- 3.5mm jack steering wheel control retention 4 ..

Installing the AXDIS-GMLN11 .................................4

Programming the AXDIS-GMLN11....................................5

Adjusting the AXDIS-GMLN11 .................................5

Steering wheel control settings .......................6-8

- L.E.D. feedback ....................................................6

- Changing radio type ...........................................6

- Remapping the steering wheel control buttons ... 7

- Dual assignment instructions (long button press) ...8

Troubleshooting .....................................................9

GM Data Interface with SWC 2006-2012

APPLICATIONS

• Provides accessory power

(12-volt 10-amp)

• Retains R.A.P. (retained

accessory power)

• Provides NAV outputs (parking

brake, reverse, speed sense)

• Retains chimes

• Retains audio controls on the

steering wheel

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Retains the factory AUX-IN jack

• Can be used in non-ampliﬁed

or ampliﬁed models

• Retains balance and fade

• Micro “B” USB updatable

• AXDIS-GMLN11 interface • AXDIS-GMLN11 harness

• 16-pin harness with stripped leads • 4-pin to 4-pin resistor pad harness

• Female 3.5mm connector with stripped leads

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G5 2007-2009

G6 (5th digit of VIN must

be a J, K, or L) 2009

PONTIAC (CONT)

G6 2010

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2007-2009

CONNECTIONS TO BE MADE

Attention! This interface will work with models that are either factory ampliﬁed, or non-

ampliﬁed. Please follow the instructions carefully for your model vehicle. Failure to do so will

result in either no sound, or low sound. If you are unsure if your vehicle is factory ampliﬁed or

not, please contact your local dealership.

For models

without

an ampliﬁer:

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

• Connect the wire to the amp turn on wire. This wire must be connected for the Blue/White

audio controls on the steering wheel to function.

• If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White

• If the aftermarket radio has a mute wire, connect the Brown wire to it. If the mute wire is

not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the Light Green wire to the parking brake wire

• Tape off and disregard the following (4) wires, they will not be used in this application:

Green Green/Black Purple Purple/Black, , , .

From the AXDIS-GMLN11 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Cut off the resistors from the , , , and wires below the Green Green/Black Purple Purple/Black

heat shrink.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

• Ensure the (2) 4-pin Molex connectors are connected together.

Note:

The 4-pin to 4-pin resistor pad harness will not be used in this application.

• The Black/Yellow wire is used for OnStar level adjustment for models that do not come

equipped with steering wheel controls. Refer to the OnStar level Adjustment section for

further instructions.

• Connect the and RCA jacks to the audio AUX-IN jacks of the aftermarket radio.Red White

• Disregard the DIN jack and wire.Red

Continue to 3.5mm jack steering wheel control retention

REV. 1/22/2020 INSTAXDIS-GMLN11

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the Light Green wire to the parking brake wire

• Tape off and disregard the following (4) wires, they will not be used in this application:

Green Green/Black Purple Purple/Black, , ,

From the AXDIS-GMLN11 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

• Disconnect the (2) 4-pin Molex connectors, and then attach the 4-pin to 4-pin resistor pad harness.

• The Black/Yellow wire is used for OnStar level adjustment for models that do not come

equipped with steering wheel controls. Refer to the OnStar level Adjustment section for

further instructions.

• Connect the and RCA jacks to the audio AUX-IN jacks of the aftermarket radio.Red White

• Disregard the DIN jack and wire.Red

Continue to 3.5mm jack steering wheel control retention

Attention! This interface will work with models that are either factory ampliﬁed, or non-

ampliﬁed. Please follow the instructions carefully for your model vehicle. Failure to do so will

result in either no sound, or low sound. If you are unsure if your vehicle is factory ampliﬁed or

not, please contact your local dealership.

For models

with

an ampliﬁer:

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

• Connect the wire to the amp turn on wire. This wire must be connected to hear Blue/White

sound from the factory ampliﬁer, and also for the audio controls on the steering wheel to

function.

• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.

• If the aftermarket radio has a mute wire, connect the Brown wire to it. If the mute wire is

not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

CONNECTIONS TO BE MADE (CONT)
