Seite 1/4
AXDI-GMLN9
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 9/14/23 INSTAXDI-GMLN9
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product.
Ensure that all installation connections,
especially the air bag indicator lights, are
plugged in before reconnecting the battery
or cycling the ignition to test this product.
NOTE: Refer also to the instructions
included with the aftermarket accessory
before installing this device.
INTERFACE FEATURES
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power)
•
Provides wires for multimedia radios (park brake, reverse, speed sense)
• Used in non-amplified models, or when bypassing a factory amplifier
• Used in models without OnStar® or when not retaining OnStar®
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Provides illumination output
• Micro-B USB updatable
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Cutting tool
• Tape
• Crimping tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
TABLE OF CONTENTS
Applications 2 ...........................................................
Connections LD-LCLAN-09.....................................3
Installation 4 .............................................................
Programming 4 .........................................................
GM Chime Interface 2014-2020
INTERFACE COMPONENTS
• AXDI-GMLN9 interface
• LD-LCLAN-09 harness
Visit for more detailed
AxxessInterfaces.com
information about the product and
up-to-date vehicle specific applications
2
APPLICATIONS
CHEVROLET
Colorado 2015-2018(1) ..........................................................................
Equinox 2018(1) .....................................................................................
Malibu 2016-2018(2) ..............................................................................
Silverado 2015-2018(3) .........................................................................
Silverado 1500 2014-2018(3) ................................................................
Silverado 2500/3500 2015-2019(3) ......................................................
Silverado LD (1) 2019 ..............................................................................
Suburban 2015-2020 ..............................................................................
Tahoe 2015-2020 ....................................................................................
GMC
Canyon 2015-2018(1) .............................................................................
Sierra 2015-2018(3) ...............................................................................
Sierra 1500 2014-2018 (3) ......................................................................
Sierra 2500/3500 2015-2019(3) ............................................................
Sierra Limited 2019(1) ...........................................................................
Yukon / Yukon XL 2015-2020 .................................................................
(1) With RPO code I05 or I06
(2) With radio code IP1
(3) With radio code IO3, IO5, or IO6
The RPO code is located in the Service Parts Identification sticker
3
REV. 9/14/23 INSTAXDI-GMLN9
CONNECTIONS: LD-LCLAN-09 DIAGRAM
Black - Ground wire
Yellow - Battery wire
Purple/Black - Rear right - output
Purple - Rear right + speaker output
White/Black - Front left - speaker
White - Front left + speaker
Gray/Black - Front right - speaker
Gray - Front right + speaker
Green/Black - Rear left - speaker output
Green - Rear left speaker + output
Green/Purple - Reverse backup camera
Light Green - Parking brake
Blue/Pink - VSS/Speed-Sense
Red - Accessory power
Orange - Illumination
Front
Rear
Sub
AUX-IN
Rear View
SWC
Aftermarket Radio
(Your radio’s features may vary)
LD-LCLAN-09
Vehicle Connector
Radio Connections
Interface
12-Pin
Vehicle Connector
